Chapter 1: Product Introduction

Knowing Your NISE 50C and NISE 50C-H

NISE 50C Front Panel

Antenna Hole LEDs
Power SIM HDMI
Switch

NISE 50C-H Front Panel

Antenna Hole LEDs
Power SIM HDMI
Switch
Copyright © 2015 NEXCOM International Co., Ltd. All Rights Reserved.
Antenna Hole
USB 2.0 LAN
Antenna Hole
USB 2.0 LAN
Antenna Hole
Used to install external antennas.
Power Switch
Press to power-on or power-off the system.
SIM
Used to insert a SIM card.
HDMI
Used to connect a high-definition display.
USB 2.0
USB 2.0 ports to connect the system with USB 2.0/1.1 devices.
LAN
Used to connect the system to a local area network.
LED Indicators
Indicates the hard drive (NISE 50C-H only), Wi-Fi and GSM activity of the
system.
4
NISE 50C/50C-H User Manual
