Chapter 2: Jumpers and Connectors
COM 2 Port (RS232)
Connector type: DB-9 port, 9-pin D-Sub
Connector location: CN2
1
5
6
9
Pin
Definition
1
N/A
3
SP2_TXD_R
5
N/A
7
N/A
9
N/A
MH1
CHASIS_GNDR
Copyright © 2015 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
2
SP2_RXD_R
4
N/A
6
N/A
8
N/A
MH2
CHASIS_GNDR
COM 3 Port (RS232)
Connector type: DB-9 port, 9-pin D-Sub
Connector location: CN1
1
5
6
Pin
Definition
1
N/A
3
SP3_TXD_R
5
N/A
7
N/A
9
N/A
MH1
CHASIS_GNDR
18
9
Pin
Definition
2
SP3_RXD_R
4
N/A
6
N/A
8
N/A
MH2
CHASIS_GNDR
NISE 50C/50C-H User Manual
