Chapter 1: Product Introduction

Hardware Specifications

CPU Support
▪ Onboard Intel
Atom™ processor E3826 Dual Core, 1.46GHz
®
▪ Support Intel
® Atom™ E3800 processor family from Single Core E3815,
Dual Core E3825/E3826/E3827 and Quad Core E3845 with different
SKUs.
Main Memory
▪ Onboard DDR3L 1066/1333 2GB RAM, un-buffered and non-ECC, max
up to 2GB
Display Option
▪ 1x HDMI display
Front I/O Interface
▪ ATX power on/off switch
▪ 1x Wi-Fi/1x GSM LEDs (NISE 50C)
▪ 1x Storage Access/1x Wi-Fi/1x GSM LEDs (NISE 50C-H)
▪ 1x SIM Card holder
▪ 1x Intel I210AT GbE LAN port, supports Wake on LAN, Teaming and PXE
▪ 1x HDMI Display Output
▪ 4x USB 2.0 (500mA per each)
▪ 2x Antenna Holes for optional Wi-Fi/3.5G antenna
Rear I/O Interface
▪ 3x DB9, only support RS232 Tx/Rx/GND signal
▪ 1x Line-out
▪ Support 12V DC input
Copyright © 2015 NEXCOM International Co., Ltd. All Rights Reserved.
I/O Interface - Internal
▪ 4x GPI and 4x GPO (5V, TTL Type)
▪ 1x DB9, only supports RS232, Tx/Rx/GND signal
Storage Device
▪ Onboard 16GB EMMC
▪ 1x 2.5" HDD (SATA 2.0) only for NISE 50C-H
Expansion Slot
▪ 3x Mini PCIe sockets for optional Wi-Fi/3.5G modules
Power Requirements
▪ Power input: 12Vdc
▪ 1x optional 12V, 60W power adapter
Support OS
▪ Windows 7 (NISE 50C-H)
▪ Windows Embedded Standard 7 (NISE 50C-H)
▪ Windows 8.1
▪ Windows Embedded Standard 8
▪ Android 4.4
Dimensions
▪ 146mm(W) x 26mm(H) x 150mm(D) (NISE 50C)
▪ 146mm(W) x 42mm(H) x 150mm(D) (NISE 50C-H)
Construction
▪ Aluminum and metal chassis with fanless design
