Chapter 2: Jumpers and Connectors

Mic-in Pin Header

Connector type: 1x4 4-pin header, 2.0mm pitch
Connector location: JP1
1 4
Pin Definition
1 MIC1_L3
2 MIC_JD
3 MIC_JD
4 MIC1_R3
Copyright © 2015 NEXCOM International Co., Ltd. All Rights Reserved.

Port 80 Connector

Connector type: 1x10 10-pin header, 1.0mm pitch
Connector location: J2
10
Pin Definition
1 GND
3 DEBUG_LPC33MHZ
5 LPC_AD3
7 LPC_AD1
9 VCC3/LPC_SERIRQ
MH1 GND
22
1
Pin Definition
2 EC_PLTRST#
4 LPC_FRAME#
6 LPC_AD2
8 LPC_AD0
10 VCC3
MH2 GND
