28. SPECIFICATION: REPEATER BATTERY BACKED PSU
Repeater Power Supply
Manufacturer/Model
Aidcall Part No.
EMC Approval
LVD Approval
Environmental Approval
Type
Input Voltage
Output Voltage/Current
Output Ripple
LED Indicators
Mains Fuse Protection
Load Fuse Protection
Battery Protection
Enclosure Material
Ingress Protection Rating
Dimensions
Weight
Operating Temperature Range
Operating Humidity
Standby Battery
Manufacturer/Model
Aidcall Part No.
Type
Dimensions
Weight
Operating Temperature Range
Mains Lead
Approvals
Cable
Plug
Fuse Type/Rating
Operating Temperature Range
Operating Humidity
Elmdene G13802N‐A
E40062 (includes PSU, Standby Battery & Mains Lead)
2014/30/EU
2014/35/EU
RoHS2: 2011/65/EC, WEEE: 2012/19/EU
Switch Mode PSU with Electronic Overload Protection
100V to 240V AC 50/60Hz
13.8V DC @ 2A
150mV peak to peak
Green = Mains Present and Red = Fault (Output/Battery Fuse Fail)
T2.0A 20mm HRC
F2.0A 20mm Glass
Re‐settable PTC
White powder coated 18 SWG steel with hinged lid
IP41 (indoor sheltered)
200mm x 230mm x 80mm (HxWxD)
1.85 kilograms (excluding battery)
o
o
‐10
C to 40
C
75% RH, Non‐condensing
Yuasa NP3.4‐12
F00040
12V 3.4Ah Rechargeable Lead Acid
133mm x 66mm x 60mm (LxWxH)
1000 grams
o
o
‐15
C to 50
C
BS 1363/A, VDE and KEMA
2 metres long 3 cores 0.75
BS 1363 moulded non‐rewireable 13A UK Plug
BS 1362 1" 240V AC 5A
o
o
10
C to 40
C
20‐80% RH, Non‐condensing
2
mm (Colour: Black)
Doc No. FM5640 issue 3 Page 45
