24. SPECIFICATION: MULTI‐CELL REPEATERS
2 Channel Multi‐Cell Repeater
Manufacturer/Model No.
Aidcall Part No.
Radio Approvals
EMC Approvals
Safety Approvals
Environmental Approvals
Max No. of Speech Channels
Typical Range
Peak Transmit Power
Typical Receiver Sensitivity
Power Input Port
Electrical Requirement
Typical Power Consumption
Enclosure
Dimensions
Weight
Operating Temperature Range
Operating Humidity
4 Channel Multi‐Cell Repeater
Manufacturer/Model No.
Aidcall Part No.
Radio Approvals
EMC Approvals
Safety Approvals
Environmental Approvals
Max No. of Speech Channels
Typical Range
Peak Transmit Power
Typical Receiver Sensitivity
Power Input Port
Electrical Requirement
Typical Power Consumption
Enclosure
Dimensions
Weight
Operating Temperature Range
Operating Humidity
Spectralink 0244 1100
ZXT512
EN 301 406, FCC Rules Part 15/Subpart D RSS‐213
EN 301 489‐1, EN 301 489‐6
UL 60950‐1, EN 60950‐1
RoHS: 2002/95/EC, WEEE: 2002/96/EC
2
20‐50 metres indoor (300 metres outdoor)
250mW
‐90dBm
FCC‐68 RJ11 4/4 Socket
9V DC, 180mA
1.62 Watts
Grey‐White ABS (NCS 0502‐Y) wall mountable, indoor use only
100mm x 100mm x 30mm (HxWxD)
113 grams
o
o
10
C to 40
C
20‐80% RH, Non‐condensing
Spectralink 0233 4601
ZXT544
EN 301 406, FCC Rules Part 15/Subpart D RSS‐213
EN 301 489‐1, EN 301 489‐6
UL 60950‐1, EN 60950‐1
RoHS: 2002/95/EC, WEEE: 2002/96/EC
4
20‐50 metres indoor (300 metres outdoor)
250mW
‐90dBm
FCC‐68 RJ11 4/4 Socket
9V DC, 180mA
1.62 Watts
Grey‐White ABS (NCS 0502‐Y) wall mountable, indoor use only
100mm x 100mm x 30mm (HxWxD)
113 grams
o
o
10
C to 40
C
20‐80% RH, Non‐condensing
Doc No. FM5640 issue 3 Page 41
