20. SPECIFICATION: MULTI CHARGER & PSU
Multi Charger Block
Manufacturer/Model No.
Aidcall Part No.
No. of Handsets per Block
No. of Blocks per PSU
Link Cable
Enclosure
Dimensions
Weight
Multi Charger Power Supply
Manufacturer/Model No.
Aidcall Part No.
Safety Approvals
EMC Approvals
Protection
LED Indicator
Input Voltage/Current
Output Voltage/Current
Efficiency
Standby Power
Max Power
Output Lead
Output Connector
Mains Lead
Mains Connectors
Fuse Type/Rating
Enclosure
Dimensions
Weight
Operating Temperature Range
Operating Humidity
Spectralink 0250 9400
W03034
5 max
3 max (15 handsets)
200mm long, fitted with 2 moulded 2.1mm Barrel Plugs (5.5mm OD)
White, desktop or wall mount, indoor use only
358mm x 63mm x 63mm (HxWxD)
450 grams
Spectralink 0250 9501 (FranMar FRA032‐S07‐4)
W03043
IEC/UL/EN 60950‐1
EN55022, EN6100‐3‐2, EN61000‐4‐2, EN55024
Electronic OVP, OLP & Short Circuit Protection
Green: Supply Healthy
100‐240VAC 47‐63Hz 1.0A
6V DC 5A
CEC Level V
<0.075 Watts
32 Watts
1 metre long black AWM 1185 16 AWG
Moulded 2.1mm Barrel Plug Centre Positive (5.5mm OD)
1.5 metres long black 227 IEC 53 (RVV) 3 core 0.75
BS 1363 moulded 13A UK Plug & moulded IEC C13 Female Plug
BS 1362 1" 240V AC 10A
Black, desktop design, indoor use only
117mm x 53mm x 31mm (LxWxD)
250 grams (exc. Mains Lead)
o
o
0
C to 40
C
20‐90% RH, Non‐condensing
2
mm
Doc No. FM5640 issue 3 Page 37
