27. SPECIFICATION: 16 & 24 PORT ETHERNET SWITCHES
16 Port Ethernet Switch (8 PoE)
Manufacturer/Model No.
Aidcall Part No.
Network Protocol & Standards
EMC Approvals
Safety Approvals
Data Rate
Network Interface
Network Ports
Status LED's
Electrical Requirement
Typical Power Consumption
Enclosure
Dimensions
Weight
Operating Temperature Range
Operating Humidity
24 Port Ethernet Switch (24 PoE)
Manufacturer/Model No.
Aidcall Part No.
Network Protocol & Standards
EMC Approvals
Safety Approvals
Data Rate
Network Interface
Network Ports
Status LED's
Electrical Requirement
Typical Power Consumption
Enclosure
Dimensions
Weight
Operating Temperature Range
Operating Humidity
Netgear ProSAFE FS116P
ZXT549
IEEE 802.3i 10Base‐T Ethernet, IEEE 802.3u 100Base‐TX Fast Ethernet
FCC Part 15 Class A, EN 55022 (CISPR 22) Class A, C‐Tick Class A
EN 60950, UL 1950, C‐Tick
100Mbps
16 x RJ45
16 auto‐speed sensing 10/100 Mbps UTP Ports, 8 with PoE
Power and Ethernet Link/Activity indicators built into RJ45 Ports
100‐240V AC 50/60Hz, Power Adapter 12V DC, 1A
5.5 Watts max
Desktop, indoor use only
287mm x 103mm x 27mm (WxDxH)
810 grams
o
o
0
C to 40
C
10‐90% RH, Non‐condensing
Netgear ProSAFE FS728TP
ZXT559
IEEE 802.3i 10Base‐T Ethernet, IEEE 802.3u 100Base‐TX Fast Ethernet
FCC Part 15 Class A, EN 55022 (CISPR 22) Class A, C‐Tick
EN 60950, UL 1950
100Mbps
24 x RJ45
24 auto‐speed sensing 10/100 Mbps UTP Ports, all with PoE
Power and Ethernet Link/Activity indicators built into RJ45 Ports
100‐240V AC 50/60Hz
15 Watts max
Desktop or 19" Rack Mount (1U), indoor use only
440mm x 257mm x 43mm (WxDxH)
3.57 kilograms
o
o
0
C to 50
C
10‐90% RH, Non‐condensing
Doc No. FM5640 issue 3 Page 44
