Aidcall Touchsafe Pro IP-DECT 400 Single-Cell Installation Manual page 30

Wireless nursecall system
Hide thumbs
Table of Contents

Advertisement

16. IP‐DECT 400 MULTI‐CELL SYSTEM INSTALLATION

3 REPEATER DEPLOYMENT EXAMPLES

3 Repeaters connected in a chain:







Repeater
Multi‐Cell Server/Base

RPN +64
RPN 3‐6

1 Repeater connected directly and 2 in a chain:







Multi‐Cell Server/Base
Repeater

RPN +64


3 Repeaters connected directly:








Repeater
Multi‐Cell Server/Base

RPN +64





Y‐shaped 3 Repeater deployment:








Multi‐Cell Server/Base
Repeater

RPN 3‐6
RPN +64

























Repeater
RPN 128
Repeater
RPN 3‐6
RPN +128
Repeater
RPN +128
RPN 3‐6
Repeater
RPN +192
Repeater
RPN +128
Repeater
RPN +192
Repeater
RPN +192
Repeater
RPN +192
Doc No. FM5640 issue 3 Page 30
