9. MULTI CHARGER & PSU
The optional Multi Charger is a modular system, each Multi Charger module can charge up to 5 Spectralink
77 Series DECT handsets at the same time. Using the included link cable, up to 3 Multi Charger modules can
be connected together horizontally or vertically to provide charging from one PSU, eliminating the need for
15 separate mains sockets, PSU's and chargers.
The Multi Charger can be desk mounted or fixed to the wall. It is possible to wall mount an unlimited
number of Multi Chargers simultaneously and it is possible to expand the numbers should your needs grow.
With the Multi Charger you can benefit from access to fully charged handsets at any time, it is easy to see
which handsets are charged and if any are missing.
Multi Charger Blocks and PSU's are ordered separately, remember; 1 PSU module can power up to 3
Charger Blocks (15 handsets).
Desk or wall mount
Multi Charger Block
for up to 5 Handsets
358mm x 63mm x 63mm
(HxWxD)
PART NUMBERS
Spectralink Ref. Aidcall Ref.
0250 9400 W03034
0250 9501 W03043
Refer to the Spectralink Handset Multi Charger installation guide (see section 6).
Product
Spectralink Multi Charger (Inc. Link Cable)
Spectralink Multi Charger UK PSU
Power Supply for up to
3 Charger Blocks
Link Cable for connecting
up to 3 Charger Blocks
Doc No. FM5640 issue 3 Page 11
