Table 4: Typical Mechanical Characteristics (cont.)
Characteristics
Dimensions, Output Cable
Unit Weight (probe only)
Shipping Weight (with
accessories)

Nominal Characteristics

The Nominal characteristics shown in the following table describe
guaranteed traits, but the traits do not have tolerance limits.
Table 5: Nominal Electrical Characteristics
Characteristics
Input Type
Output Type
Range Settings
P5200 Instruction Manual
Description
1.8 m (6 ft)
315 g (11 oz)
1.42 kg (3 lb, 2 oz)
Description
Balanced differential
Single-ended, load impedance must be greater than
50 kΩ for stated accuracy
Switchable: 1/50 and 1/500
Specifications
17
