Compliance Information
Radiated and Conducted Emissions
FCC Code 47 CFR. Part 15, Subpart B, Class A
VFG 0243 Enclosure: EN 5502 Class B limits for radiated emissions
AC Mains: EN 55022 Class B limits for conducted emissions and EN
60555-2 AC power harmonic emissions
To ensure compliance with the above requirements, only high quality
shielded interface cables should be attached to this instrument. High
quality cables have a reliable, continuous outer shield (braid and foil)
that has low impedance connections to shielded connector housings at
both ends. The following cables meet this criteria:
GPIB: Tektronix part numbers 012-0991-00, -01, -02, -03
RS-232: Tektronix part number 012-1380-00
Printer: Tektronix part number 012-1250-00
Immunity, Enclosure, Radio Frequency Electromagnetic Field
IEC 801–3 Tested with TDS460 set to 50 mV/Div vertically and
500 μs/Div horizontally
Immunity, Enclosure, Electrostatic Discharge (ESD)
8 kV, IEC 801–2
Immunity, Fast Transients, Common Mode
IEC 801–4
Immunity, AC Power Line Transients
IEC 801–5
viii
P5200 Instruction Manual
