UM1467
A binary images (*.hex and *.dfu) of this demonstration is provided under Binary subfolder.
You can use the STM32F4xx's embedded Bootloader or any in-system programming tool to
reprogram the demonstration using this binary image.
3.2.2

Master_Workspace subfolder

This subfolder contains, for some toolchains, a multi-project workspace allowing you to
manage all the available projects (provided under the subfolders listed below) from a single
workspace window.
3.2.3

Peripheral_Examples subfolder

This subfolder contains a set of examples for some peripherals with preconfigured projects
for EWARM, MDK-ARM, TrueSTUDIO and TASKING toolchains. See
STM32F4DISCOVERY peripheral firmware examples, AN3983, for further details.
3.3

Utilities folder

This folder contains the abstraction layer for the STM32F4DISCOVERY hardware. It
provides the following drivers:
– stm32f4_discovery.c: provides functions to manage the user push button and 4 LEDs
(LD3.LD6)
– stm32f4_discovery_audio_codec.c/.h: provides functions to manage the audio DAC
(CS43L22)
– stm32f4_discovery_lis302dl.c/.h: provides functions to manage the MEMS
accelerometer (LIS302DL).
Doc ID 022172 Rev 1
Description of the firmware package
Section 5 and
8/46
