Using MDK-ARM Microcontroller Development Kit by Keil™
7.3.2
Configuring project options
1.
In the Project menu, select Options for Target 1 to display the Target Options dialog
box.
2.
Open the Target tab and enter IROM1 and IARM1 start and size settings as shown in
Figure
Figure 32. Target Options dialog box - Target tab
3.
Open the Debug tab, click Use and select the ST-Link Debugger. Then, click Settings
and select the SWD protocol. Click OK to save the ST-Link setup settings.
4.
Select Run to main().
25/46
32.
Doc ID 022172 Rev 1
UM1467
