1. Controller locate UID
2. Controller status LED
3. Controller fault LED
4. USB type A port
5. Recovery/power button (See Recovery/power
button).
1
Figure 5: HPE StoreVirtual 3200 Storage 1 GbE controller module (4 port)
1. Controller locate UID
2. Controller status LED
3. Controller fault LED
4. USB type A port
5. 1 GbE ports
6. Recovery/power button (See Recovery/power
button).
1
Figure 6: HPE StoreVirtual 3200 Storage 10 GbE controller module (2 port)
2
3
4
5
6
7
2
3
4
5
6
7
6. Service port (Micro-B USB)
7. Management port (MGMT)
8. 1 GbE ports
9. Data port status LEDs
10. SAS data port to optional drive enclosure
(DP-1)
8
9
10
11
7. Service port (Micro-B USB)
8. Management port (MGMT)
9. 1 GbE ports
10. Data port status LEDs
11. SAS data port to optional drive enclosure
(DP-1)
8
9
10
11
Product overview
7
