3. Verify the Item—This is the name of the system, controller, or disk, or the version number. Verify that
the controllers "see" each other.
4. Result—This is the outcome of the scan. If all components have a status of OK, you can continue with
the configuration. Negative statuses can be returned for issues such as errors communicating with
controllers or drives, and mismatched software versions.

Configuring Disk Raid

The recommended disk RAID levels are displayed. The RAID levels are determined based on the system
hardware configuration and provide optimum capacity, performance, and data protection.
Procedure
• If you want to change the disk RAID levels, click Change RAID.
For further instructions, go to Changing the Disk RAID .
• If you accept the default configuration, go to the section appropriate for your configuration:
◦ Network configuration for Fibre Channel systems
◦ Network configuration for iSCSI systems

Changing the Disk RAID

If you chose Change Raid in the Configure Disk RAID window, the Add Disk Raid window is displayed.
You can select another RAID based on the number of disks and their desired usage characteristics, such
as performance or capacity. If tiered disks are discovered, you are presented with options using the tiers.
Disks are automatically assigned to a storage tier. Only valid, symmetrical RAID configuration options are
presented and can be selected.
Procedure
1. To change the configuration for a specific tier, select Configure for the tier, and Add at the bottom of
the window.
2. On the configuration window for the chosen tier, click Select RAID Type.
3. The valid configurations for the tier will be displayed in the Configuration description list. Select a
configuration and click OK.

Data network configuration

The network ports that are displayed have been discovered on the system. HPE recommends bonding
the network ports. The data and management traffic take place on the bonded interfaces.
You can configure either a Fibre Channel system or an iSCSI system.
• For Fibre Channel systems, see Network configuration for Fibre Channel systems
• For iSCSI systems, see Network configuration for iSCSI systems
For more information about configuring and managing the HPE StoreVirtual 3200 Storage network, see
the HPE StoreVirtual 3200 Storage User Guide.
