HPE StoreVirtual 3200 Installation Manual page 13

Table 5: Array controller module status LEDs
Blue UID LED
Off
Off
Off
Off
On
Flash
On
Flash
Ethernet LED statuses
The LED statuses described in the Ethernet Led statuses table behave the same way for the following
components:
• Management ports
• Onboard 1 GbE LEDs
• 1 GbE LOM LEDs
• 10 GbE LOM LEDs
Table 6: Ethernet LED statuses
Green LED
Off
Off
Flash
Green Amber status
power LED LED
Off Off
On Off
Off Solid
On Flash
On Off
On Off
Off On
Off On
Amber LED
Off
On
On
Description
No power
Powered on, no fault
Fault
Predictive failure
Manually initiated locate, no fault, safe to
remove
Manually initiated locate, no fault,
do not remove
Automatically initiated locate, fault, safe to
remove
Automatically initiated locate, fault, do not
remove
Description
Fault or no power
Link without activity
Link with activity
Ethernet LED statuses 13
