- Page 1 PCIe Card Replacement HPE Alletra 5000 HPE Nimble Storage AFxx, HFxx HPE Nimble Storage AFxxxx, CSxxxx, CSxxx, SFxxx Published May, 2023 Part No. 960-0048-003 Revision C *960-0048-003*...
-
Page 2: Legal Notices
Document ID xeq1501854780875 Support All documentation and knowledge base articles are available on HPE InfoSight at https://infosight.hpe.com. To register for HPE InfoSight, click the Create Account link on the main page. Email: support@nimblestorage.com For all other general support contact information, go to https://www.hpe.com/us/en/services/nimble-storage.html. -
Page 3: Replacement Guide
HPE recommends using the Maintenance Window functionality within the HPE InfoSight portal to inform HPE Support of upcoming maintenance windows. Go to HPE InfoSight > HPE Alletra 6000, Alletra 5000, Nimble Storage > Wellness > Manage Maintenance Windows for more information. - Page 4 2 PCIe cage b For HPE Alletra 5010 or Nimble Storage AF20 and HF20 models: Grasp both sides of the PCIe cage and lift the cage out of the controller, making sure that the cage clears the guide pins and that both riser cards and the bridge board connector are properly unseated.
- Page 5 Documentation Feedback: doc-feedback-hpe-storage@hpe.com Guide pins Bridge board 2 Riser card c For all other models: Grasp both sides of the PCIe cage and lift the cage out of the controller making sure the cage clears the guide pins and that the underlying riser cards are properly unseated from their connectors.
- Page 6 Documentation Feedback: doc-feedback-hpe-storage@hpe.com a The PCIe card holder protrudes through the top of the PCIe cage in three sections. Push down on the center section and slide the PCIe card holder in the direction of the arrow to loosen it from the cage.
- Page 7 Documentation Feedback: doc-feedback-hpe-storage@hpe.com b Pull the PCIe card out of the card slot. Note: If you are installing a quad port 10Gb SFP+ NIC card, you must remove the transceivers from the ports before attempting to the install the card.
- Page 8 Turn the PCIe cage right side up. b For HPE Alletra 5010 or Nimble Storage AF20 and HF20 models: Lower the PCIe cage back into the controller, making sure that the PCIe cage aligns with the guide pins, and that the riser card with the bridge board connector aligns with the bridge board.
- Page 9 Documentation Feedback: doc-feedback-hpe-storage@hpe.com Guide pins Bridge board 2 Riser card To replace the controller shroud: 1 Align the notches in the shroud (marked by arrows) with the pegs on the controller. 2 Lower the shroud into place, making sure the tabs on the shroud seat properly in the controller.
- Page 10 (gray) status. HBA ports cannot be configured for management traffic. Replace a PCIe Card (HPE Nimble Storage AFxxxx, CSxxxx, SFxxx) Use this procedure to replace existing network interface cards (NICs) or host bus adapters (HBAs) on your HPE Nimble Storage array.This procedure applies to the following models:...
- Page 11 HPE recommends using the Maintenance Window functionality within the HPE InfoSight portal to inform HPE Support of upcoming maintenance windows. Go to HPE InfoSight > HPE Alletra 6000, Alletra 5000, Nimble Storage > Wellness > Manage Maintenance Windows for more information.
- Page 12 Documentation Feedback: doc-feedback-hpe-storage@hpe.com Figure 1: Controller rear view Note: Do not remove the power cord above the controller. If clips are installed, it is recommended to secure retention clips around the power cord to avoid accidental power cord removal or displacement.
- Page 13 Documentation Feedback: doc-feedback-hpe-storage@hpe.com Thumbscrews Retention bracket 4 Replace the PCIe card. a Remove the existing NIC or HBA from the slot (see diagram in step 2). If you are installing a quad port 10Gbps SFP+ NIC card, you must remove the transceiver from port 1 before attempting to install the card.
- Page 14 Documentation Feedback: doc-feedback-hpe-storage@hpe.com Note: If the PCIe cage does not have a retention bracket, go to Step 5b. Slide the retention bracket in to secure the PCIe cards, then fasten the two thumbscrews to lock the retention bracket in place.
