Specifications

7.1.2 FCP 106 Dimensions

Illustration 7.2 FCP 106 Dimensions
1)
Power
[kW (hp)]
Enclosure
type
3x380–480 V
MH1 0.55–1.5 (0.75–2.0) 231.4 (9.1) 130 (5.1) 162.1 (6.4) 106.8 (4.2)
MH2 2.2–4.0 (3.0–5.0)
MH3 5.5–7.5 (7.5–10)
Table 7.3 FCP 106 Dimensions
1) Power ratings relate to NO, see chapter 7.2 Electrical Data.
MG03L302
Operating Instructions
Y
X
Length Width
[mm (in)] [mm (in)]
A a B
276.8 (10.9) 166 (6.5) 187.1 (7.4) 113.2 (4.5)
321.7 (12.7) 211 (8.3) 221.1 (8.7) 123.4 (4.9)
Danfoss A/S © 11/2015 All rights reserved.
Height
[mm (in)]
Normal lid High lid for
®
VLT PROFIBUS DP
MCA 101
option
C C
121.4 (4.8)
127.8 (5.0)
138.1 (5.4)
Cable gland Mounting
diameter hole
X Y
M20 M20 M6
M20 M20 M6
M20 M25 M6
41
7 7
