Specifications
E
T LA
C
Motor frame size 71
M [mm (in)] 130 (5.1)
N [mm (in)] 110 (4.3)
P [mm (in)] 160 (6.3)
S [mm (in)] M8
T [mm (in)] 3.5 (0.14)
LA [mm (in)] 10 (0.4)
HA [mm (in)] HA = AC1 + height of the frequency converter.
For frequency converter dimensions, see Table 7.3.
®
HD [mm (in)] without VLT PROFIBUS DP MCA 101
MH1 247 (9.7)
MH2 248 (9.8)
MH3 –
®
HD [mm (in)] with VLT PROFIBUS DP MCA 101
MH1 262 (10.3)
MH2 263 (10.4)
MH3 –
Table 7.5 FCM 106 Dimensions: Flange Mounting - B5, B35 for Asynchronous or PM Motor
MG03L302
Operating Instructions
80 90S 90L
165 (6.5) 165 (6.5) 165 (6.5)
130 (5.1) 130 (5.1) 130 (5.1)
200 (7.9) 200 (7.9) 200 (7.9)
M10 M10 M10
3.5 (0.14) 3.5 (0.14) 3.5 (0.14)
10 (0.4) 12 (0.5) 12 (0.5)
267 (10.5) 286 (11.3) 286 (11.3)
268 (10.6) 287 (11.4) 287 (11.4)
– 299 (11.8) 299 (11.8)
282 (11.1) 301 (11.9) 301 (11.9)
283 (11.2) 302 (11.9) 302 (11.9)
– 314 (12.4) 314 (12.4)
Danfoss A/S © 11/2015 All rights reserved.
100L 112M 132S
215 (8.5) 215 (8.5) 265 (10.4)
180 (7.8) 180 (7.8) 230 (9.1)
250 (9.8) 250 (9.8) 300 (11.8)
M12 M12 M12
4 (0.16) 4 (0.16) 4 (0.16)
14 (0.6) 14 (0.6) 14 (0.6)
– – –
304 (12) 332 (13.1) –
316 (12.4) 244 (9.6) 379 (14.9)
– – –
319 (12.6) 347 (13.7) –
331 (13.1) 359 (14.1) 394 (15.5)
