Commissioning

5.4.3 Quick Menu Motor Set-up

The Quick Menu Motor Set-up guides the installer through setting of the required motor parameters.
NOTICE
MOTOR OVERLOAD PROTECTION
Thermal protection of the motor is recommended. Especially when running at low speed, the cooling from the
integrated motor fan is often not sufficient.
•
Use PTC or Klixon, see chapter 4.6.2 Thermistor Input from Motor, or
•
Enable motor thermal protection by setting parameter 1-90 Motor Thermal Protection to [4] ETR trip 1.
PM Motor
1-24 Motor Current
3.8 A
1-25 Motor Nominal Speed
3000 RPM
1-26 Motor Cont. Rated Torque
5.4 Nm
1-30 Stator Resistance
0.65 Ohms
1-39 Motor Poles
8
1-40 Back EMF at 1000 RPM
57 V
Illustration 5.8 Quick Menu Motor Set-up
MG03L302
Operating Instructions
0-03 Regional Settings
[0] International
0-06 Grid Type
[12]] 380-440V/50Hz
1-00
[3] Closed Loop
1-10 Motor Type
[0] Asynchronous
Motor Type = IPM
1-38 q-axis inductance(Lq)
5 mH
IPM Type = non-Sat.
(1-70) PM Start Mode
[0] Rotor Detection
1-46 Position Detection Gain
100 %
30-22 Locked Rotor Detection
[0]
30-23 Locked Rotor Detection Time[s]
0.10 s
4-19 Max Ouput Frequency
0065 Hz
4-12 Motor speed low limit
0016 Hz
4-13 Motor speed high limit
0050 Hz
3-41 Ramp 1 ramp-up time
0003 s
3-42 Ramp1 ramp-down time
0003 s
MotorType = PM Motor
Danfoss A/S © 11/2015 All rights reserved.
Asynchronous Motor
1-20 Motor Power
1.10 kW
1-22 Motor Voltage
400 V
1-23 Motor Frequency
50 Hz
1-24 Motor Current
04.66 A
1-25 Motor nominal speed
1420 RPM
1-44 d-axis Inductance Sat. (LdSat)
IPM Type = Sat.
5
mH
(1-45) q-axis Inductance Sat. (LqSat)
5
mH
(1-48) Current at Min Inductance for d-axis
100
%
1-49 Current at Min Inductance for q-axis
100
%
MotorType = Asynchronous
1-73 Flying Start
[0] No
5 5
