Mechanical Installation

3 Mechanical Installation

3.1 Unpacking

NOTICE
INSTALLATION - EQUIPMENT DAMAGE RISK
Incorrect installation can result in equipment damage.
•
Before installation, check for fan cover damage,
shaft damage, foot or mounting damage, and
loose fasteners.
•
Check nameplate details.
•
Ensure level mounting surface, balanced
mounting. Avoid misalignment.
•
Ensure that gaskets, sealants, and guards are
correctly fitted.
•
Ensure correct belt tension.

3.1.1 Items Supplied, FCP 106

Check that all items are included:
•
1 FCP 106 frequency converter.
•
1 accessory bag.
•
®
1 VLT Memory Module MCM 101.
•
Operating instructions.

3.1.2 Further Items Required, FCP 106

•
1 adapter plate (wall mount adapter plate or
motor adapter plate).
•
1 gasket, used between motor adapter plate and
frequency converter.
•
1 motor connector.
•
4 screws for fastening frequency converter to
adapter plate.
•
4 screws for fastening motor adapter plate to
motor.
•
Crimp terminals:
- AMP standard power timer contacts
female, see chapter 4.6.1 Connect FCP
106 to Motor for ordering numbers.
- 3 pieces for motor terminals, U, V, and
W.
- 2 pieces for thermistor (optional).
-
1 piece for grounding terminal.
•
2 guiding pins (optional).
MG03L302
Operating Instructions

3.1.3 Items Supplied, FCM 106

Check that all items are included:
•
•
•

3.1.4 Identification of Unit

Items supplied may vary according to product configu-
ration.
•
•

3.1.5 Nameplates

VLT
1
11
T/C: FCP106P4K0T4C66H1FSXXAXX
10
P/N: 134G2844
9
4.0kW(400V) / 5.0HP(460V)
8
IN: 3x380-480V 50/60Hz , 8.3/6.8A
7
OUT: 3x0-Vin 0-400Hz , 9.0/8.2A
Enclosure: IP66 , Tamb. 40 C / 104 F
1 Type code
2 Certifications
3 Enclosure rating
4 Bar code for manufacturer use
5 Certifications
6
Serial number
Enclosure type and IP rating, maximum ambient
7
temperature without derating
Output voltage, frequency, and current (at low/high
8
voltages)
9 Input voltage, frequency, and current (at low/high voltages)
10 Power rating
11 Ordering number
Illustration 3.1 FCP 106 Nameplate (Example)
1) Example of format: Serial number 'xxxxx253' indicates
manufacture in week 25, year 2013.
Danfoss A/S © 11/2015 All rights reserved.
1 FCM 106 frequency converter with motor.
1 accessory bag.
Operating Instructions.
Make sure the items supplied and the information
on the nameplate correspond to the order confir-
mation.
Check the packaging and the frequency converter
visually for damage caused by inappropriate
handling during shipment. File any claim for
damage with the carrier. Retain damaged parts
for clarification.
R Drive Motor
www.danfoss.com
S/N: 010400G253
o
o * 1 3 1 U 3 9 3 0 0 1 0 1 0 2 G 2 9 0 *
6 5
1)
3 3
2 3
Enclosure rating: See manual
E134261 Ind. Contr. Eq.
MADE IN
DENMARK
4
11
