Electrical Installation
4.3 EMC-compliant Installation
4.3.1 EMC-compliant Electrical Installation
4
4
1
1
PLC
2
Motor
3
Frequency converter
4
Minimum 200 mm (7.87 in) clearance between control cable, mains cable, and mains motor cable.
Illustration 4.3 EMC-compliant Electrical Installation, FCP 106
20
7
L1
L2
L3
PE
Danfoss A/S © 11/2015 All rights reserved.
VLT® DriveMotor FCP 106/FCM 106
2
4
6
5
5
Control cables
6
Mains, 3-phase, and reinforced PE
7
Cable insulation (stripped)
3
MG03L302
