Electrical Installation
9
8
7
6
5
4
1 U, V, W (motor phases)
2 M , M (motor thermistor wires)
T1 T2
3 PE
4 Gasket between motor and motor bracket
5 Motor cables
Illustration 4.5 Connecting FCP 106 to Motor
MG03L302
Operating Instructions
6 Adapter plate
7 Motor connector gasket
8 Motor connector
9 Frequency converter
10 Fastening screw
Danfoss A/S © 11/2015 All rights reserved.
10
W
V
U
M M
PE
T1
T2
3
4 4
1
2
