User Manual
Ascom Myco Smartphone
The table below shows the charging time when using the different ways of charging.
Charging Type:
Battery Charging Rack:
Handset Charging Rack:
Micro USB cable with recommended
Power supply unit in a wall socket:
Micro USB cable in a switched on PC: Approx. 4.5 hours
4.11.1

Charge the Handset in a Charging Rack

TIP: The handset can be configured to clear all existing messages and alerts, mute the
loudspeaker, or to automatically log out the user when placed in a Charging Rack, refer to the
Configuration Manual, Ascom Myco Smartphone.
1 Place the handset in a Charging Rack slot. The charging screen appears as soon as the
handset is correctly inserted, and shows the current charge level, refer to
Indication
2 Allow the handset to charge fully. It takes approximately 3.5 hours with a fully depleted
battery.
The handset is fully charged, and ready to use, when the charging screen shows 100%, and
the top LED light is fixed green.
TIP: We recommend to always charge the battery fully to extend the battery life, although no
harm is made to the handset, if removed from the Charging Rack before the battery has
been 100% recharged.
3 To remove it from the Charging Rack, lean the handset forward slightly and pull.
NOTE: If the handset is switched off when it is placed in the charging rack, it will
automatically switch on in charger mode once the battery level has reached
a sufficient level
a.This only applies to Ascom Myco 2, whereas the previous model will not automatically switch on
in charger mode.

4.11.2 Charge the Battery in a Battery Charging Rack

TIP: For instructions on how to remove and insert the handset battery, see
Battery on page 26.
1 Place the Battery Pack in one of the Battery Charging Rack slots.
2 Slide the battery lock to the left.
The LED light under the slot turns red when the battery is correctly inserted.
3 Allow the battery to charge fully. It takes approximately three hours with a fully depleted
battery.
The handset is fully charged, and ready to use, when the charging screen shows 100%, and
the top LED light is fixed green.
TIP: We recommend to always charge the battery fully to extend the battery life. Although,
there is no harm made to the battery if removed from the Battery Charging Rack before it is
charged completely, that is, when the LED light beneath the slot still shows red.
4 Slide the battery lock to the right.
14 May 2018 / Ver. K
on page 25.
a
4. Basics
Charging Time (fully depleted handset):
Approx. 3 hours
Approx. 3.5 hours
Approx. 4.5 hours
TD 93066EN
4.11.4 Charging
4.12 Change the
24
