Battery Level Indication

NOTE: The handset's indicated battery level might not always be a reliable measure of how
much charge the battery has left, especially after exchanging batteries. Connect the
handset to a charger to receive a more reliable measure, see
Battery
During a call, only the battery warning beep notifies the user. The battery warning beep
cannot be silenced during a call. When not in call, the beep is silenced by pressing the
Volume down button.

4.10 Charge the Handset Battery

TIP: The handset is delivered with approximately 50% battery charge, and doesn't need to
be charged before use.
The handset has a rechargeable lithium-ion battery. To charge it, use either a Charging Rack,
or a Micro-USB cable. A Charging Rack (for the handset, or the battery) is recommended for
fastest and most reliable charging.
The table below shows the charging time when using the different ways of charging.
Charging Type:
Battery Charging Rack:
Handset Charging Rack:
Micro USB cable with recommended
Power supply unit in a wall socket:
Micro USB cable in a switched on PC:

4.10.1 Charge the Handset in a Charging Rack

TIP: The handset can be configured to clear all existing messages and alerts, mute the
loudspeaker, or to automatically log out the user when placed in a Charging Rack, refer to
the Configuration Manual, Ascom Myco Wi-Fi and Cellular Smartphone.
1 Place the handset in a Charging Rack slot. The charging screen appears as soon as the
handset is correctly inserted, and shows the current charge level, refer to
Charging Indication
3 October 2017 / Ver. H
4. Basics
on page 21.
The Full battery icon is displayed in the status bar when the battery is fully
charged.
The Half battery icon is displayed in the status bar when the battery has
50% of its charge left.
The Low battery icon is displayed in the status bar when the battery has
15%, or less charge left. In addition, the handset beeps once, the LED flashes
orange, and the dialog window Battery low! Charge now! appears.
The Empty battery icon is displayed in the status bar when the battery has
5%, or less charge left. In addition; the handset beeps once every two
minutes, the LED flashes red, and the dialog window Battery empty!
Shutting down! appears.
on page 23.
Charging Time (fully depleted handset):
Approx. 3 hours
Approx. 4 hours
Approx. 4.5 hours
Approx. 4.5 hours
