Handset Description

All handset versions share the same external characteristics.
The handset is positioned within an arm's length from the user in normal use, usually in one of
the user's scrubs pockets or in the hand of the user.
This chapter includes the following sections:
•

3.1 Handset Overview

• 3.2 Accessories
3.1 Handset Overview
Figure 4. Overview of the handset externals.
1 Speaker.
2 Front microphone (main)
3 Charging connector / Headset connector
4 Home button
5 Front display with Touchscreen
6 Volume button, Up and Down
7 Power button
8 Proximity sensor
9 Multifunction
14 May 2018 / Ver. K
3. Handset Description
on page 10
on page 13
21
(3.1.1 Home Button on page 11)
(3.1.2 Volume Button, Up and Down
(3.1.3 Power Button
(3.1.6 Proximity Sensor
a
/Alarm button (3.1.7 Multifunction, and Alarm Button
23
22
on page 11)
on page 12)
TD 93066EN
on page 11)
on page 12)
