User Manual
Ascom Myco Smartphone
2.

Quick Installation Steps for Administrators

An administrator should perform the following steps to get the handset started:
NOTE: Remove the protective plastic sheet attached to the display, for proper
function of the touchscreen.
1 Insert the micro-SIM card (Cellular handset versions only). Refer to
page 6.
NOTE: Only a micro-SIM size card can be used in the handset.
2 Close the battery cover, and lock it. Refer to
TIP: The battery has an approximately 50% charge at delivery, and does not need to be
charged before use.
3 Change the language (if other than the default english). Refer to
page 85.
4 Enter the handset ID (Easy deployment). Refer to
page 7.
NOTE: If not already done as prerequisite, perform Easy deployment. Refer to the
Configuration Manual, Ascom Myco Smartphone.
5 Configure parameter settings for the site, or for the handset user. Refer to the Configuration
Manual, Ascom Myco Smartphone for further information.
2.1

Insert SIM Card

NOTE: Cellular handset version only. Only micro-SIM size cards can be used in the
handset.
1 Unlock the battery cover lock, and then remove the battery from the handset.
2 The SIM card slot is located under the clip. Press the upper part of the clip to open it fully,
and insert the micro-SIM in the SIM card slot, in the direction as shown on the label.
TIP: If needed, use a tweezer to hold the SIM card, and then push it into the slot.
3 Close the battery cover, and then lock it. The handset starts within seconds, if the battery is
charged.
TIP: If the handset does not start, charge the battery, and then long press the Power button
to turn the handset On.
Remove SIM Card
1 Open the battery cover lock. Press the clip to open it fully, and remove the Battery Pack.
2 Remove the micro-SIM card by using a 3-4 mm screwdriver, or similar tool, in the hole above
the SIM card slot, and pull outwards, until the micro-SIM card can be removed (with your
fingers, or with a tweezer).
CAUTION:
14 May 2018 / Ver. K
2. Quick Installation Steps for Administrators
Be careful not to damage the inside of the SIM card slot.
2.1 Insert SIM Card
4.12 Change the Battery
16.3 Languages Settings
2.2 Install and Configure the Handset
TD 93066EN
on
on page 26.
on
on
6
