Ascom Myco Wi-Fi and Cellular Smartphone
• The status of a charging handset can be indicated through a special charging screen, or
on the regular user interface, depending on the configuration, see
indication

4.10.1 Charge the handset in a Charging Rack

TIP: The handset can be configured to clear all existing messages and alerts, be set to mute,
or to automatically log out the user when placed in a Charging Rack. Refer to the
Configuration
Do the following to charge the handset in a Charging Rack:
1 Place the handset in a Charging Rack slot. The charging screen appears as soon as the
handset is correctly inserted, and shows the current charge level, refer to
Charging indication
2 Allow the handset to charge fully. It takes approximately three and a half hours with
a fully depleted battery.
The handset is fully charged, and ready to use, when the charging screen shows
100%, and the top LED light is fixed green.
TIP: It is recommended to always charge the battery fully to extend the battery life,
although no harm is made to the handset if removed from the Charging Rack before
the battery has been 100% recharged.
3 To remove it from the Charging Rack, lean the handset forward slightly and pull.

4.10.2 Charge the battery in a Battery Charging Rack

TIP: For instructions on how to remove and insert the handset battery, see
Battery on page 20.
Do the following to charge the battery in a Battery Charging Rack:
1 Place the Battery Pack in one of the charging slots.
2 Slide the battery lock to the left.
The LED under the slot turns red when the battery is correctly inserted.
3 Allow the battery to fully charge. It takes approximately three hours with a fully
depleted battery.
The battery is fully charged, when the LED under the charging slot turns green.
TIP: It is recommended to always charge the battery fully to extend the battery life,
although there's no harm made to the battery if removed from the Battery Charging
Rack before fully charged (when the LED is still red).
4 Slide the battery lock to the right.
5 Remove the battery by lifting it up.
NOTE: The Battery Pack can be difficult to remove from the slot the first few times of usage.

4.10.3 Charge with a Micro USB cable

WARNING: It is strongly recommended to use the Micro USB cable together with the USB
NOTE: The handset must be switched on to use full charging speed when charging with a
Micro USB cable. Charging with a Micro USB cable is always slower than charging in a
26 April 2016 / Ver. D
4. Basics
on page 19.
Manual.
on page 19.
Power supply unit available from Ascom (Art.No. 660468, delivered with
interchangeable plugs for EU, UK, USA/CA, and AU/NZ). To use a non-tested or
budget USB charger could cause serious injury or death.
TD 93066EN
4.10.4 Charging
handset
4.10.4
4.11 Change
18
