7.4.1

Colors

Colors can be used to show the category, or priority of an alert. The color of an alert is shown
by a color bar to the left of each alert in the alert view. For incoming alerts, the color is also
shown on the color-coded LED beacon, refer to 11.2 Color-Coded LED Signals on page 69.
Figure 42. Alerts labeled with colors.
The following colors are available:
• Red
• Green
• Blue
• Yellow
• Orange
• Cyan
• Purple
• Pink
• Dark Red
• Brown
• Grey
• White
• Black
The table below is an example of how colors are used to show priority for patient monitoring
systems:
Priority Color Priority
Red
Yellow
Cyan
NOTE: The use of colors is dependant on configuration, and can differ between
system setups.
14 May 2018 / Ver. K
7. Alerts
Used for Event
High High priority alert
Medium Medium priority alert
Low Low priority alert
Indications (if enabled)
Top display notification, red flashing
LED beacon, sound, and vibrator.
IMPORTANT: These indications are
always enabled, and cannot be
turned off
Top display notification, yellow
flashing LED beacon, sound, and
vibrator.
Top display notification, fixed cyan
LED beacon, sound, and vibrator.
TD 93066EN
56
