User Manual
Ascom Myco Wi-Fi and Cellular Smartphone
3.

Handset Description

Both handset versions (Wi-Fi, and Wi-Fi & Cellular) share the same external characteristics.
• For an overview of the handset hardware, see
• For a list of available handset accessories, see
3.1

Handset Overview

1 Speaker.
2 Front microphone (main)
3 Charging connectors
4 Home button
5 Main display with Touchscreen
6 Volume button (Up and Down)
7 Power button
8 Proximity sensor
9 Alarm/Multifunction
10 Top display
11 Color-coded LED priority beacon
12 Loudspeaker
26 April 2016 / Ver. D
3. Handset Description
(3.1.1 Home button on page 8)
(3.1.2 Volume button, up and down
(3.1.3 Power button on page 8)
(3.1.4 Proximity sensor
a
button (3.1.5 Alarm or Multifunction button
(3.1.6 Top display on page 9)
(10.2 Color-coded LED Signals
3.1 Handset Overview
3.2 Accessories on page 9.
on page 8)
on page 53)
TD 93066EN
on page 7.
on page 8)
on page 8)
