Handset Description

Both handset versions (Ascom Myco Wi-Fi, and Ascom Myco Wi-Fi and Cellular) share the
same external characteristics.
This chapter includes the following sections:
•

3.1 Handset Overview

• 3.2 Accessories
3.1 Handset Overview
1 Speaker.
2 Front microphone (main)
3 Charging connector / Headset connector
4 Home button
5 Front display with Touchscreen
6 Volume button, Up and Down
7 Power button
8 Proximity sensor
9 Multifunction
10 Top display
3 October 2017 / Ver. H
3. Handset Description
on page 9
on page 12
21
(3.1.1 Home Button
(3.1.2 Volume Button, Up and Down
(3.1.3 Power Button
(3.1.6 Proximity Sensor
a
/Alarm button (3.1.7 Multifunction, and Alarm Button
(3.1.8 Top Display on page 11)
23
22
on page 10)
on page 10)
on page 11)
TD 93066EN
on page 10)
on page 11)
9
