Altronix Maximal11DV Installation Manual page 2

MaximalDV Access Power/Controllers distribute and switch power to access control systems and accessories. They convert a 220VAC
(working range 198VAC - 256VAC), 50/60Hz input into sixteen (16) independently controlled 12VDC or 24VDC PTC protected
outputs. These Fail-Safe/Fail-Secure power outputs may be converted to dry form "C" contacts. The outputs are activated by an open
collector sink or normally open (NO) dry trigger input from an Access Control System, Keypad, Push Button, REX PIR, etc. Units
will route power to a variety of access control hardware devices including: Mag Locks, Electric Strikes, Magnetic Door Holders, etc.
The FACP Interface enables Emergency Egress, Alarm Monitoring, or may be used to trigger other auxiliary devices. The fire alarm
disconnect feature is individually selectable for any or all of the sixteen (16) outputs.
Output Voltage Options
Altronix
Power Supply 1 Power Supply 2
Model Number
AL400XB2V
12VDC @ 3.5A 12VDC @ 3.5A
Maximal11DV
12VDC @ 2.7A 24VDC @ 2.7A
24VDC @ 3.5A 24VDC @ 2.7A
AL600XB220
12VDC @ 5.5A 12VDC @ 5.5A
Maximal33DV
12VDC @ 5.7A 24VDC @ 5.7A
24VDC @ 5.5A 24VDC @ 5.7A
AL1012XB220 AL1012XB220
Maximal55DV
12VDC @ 9.5A 12VDC @ 9.5A
AL1012XB220
Maximal75DV
12VDC @ 9.5A 24VDC @ 9.5A
AL1024XB2V
Maximal77DV
24VDC @ 9.7A 24VDC @ 9.7A
• Sixteen (16) independently trigger controlled outputs.
Output options:
a) Sixteen (16) Fail-Safe filtered and electronically regulated power outputs.
b) Sixteen (16) Fail-Secure filtered and electronically regulated power outputs.
c) Sixteen (16) form "C" relay outputs (rated @ 5A/28VDC or VAC).
d) Any combination of the above.
• Sixteen (16) Access Control System trigger inputs.
Input trigger options:
a) Sixteen (16) normally open (NO) dry trigger inputs.
b) Sixteen (16) open collector inputs.
c) Any combination of the above.
• Sixteen (16) unswitched filtered and electronically regulated aux. power outputs (outputs are rated @ 2.5A).
• Red LEDs on ACM8CB board indicate individual outputs are triggered (relays energized).
• Fire Alarm disconnect (latching or non-latching) is individually selectable for any or all of the sixteen (16) outputs.
Fire Alarm disconnect input trigger options:
a) Normally open (NO) or normally closed (NC) dry trigger input.
b) Polarity reversal input from FACP signaling circuit.
• Green LED on ACM8CB board indicates FACP disconnect is triggered.
• FACP output relay indicates that FACP input is triggered (form "C" contact rated @ 1A/28VDC).
- 2 -
MaximalDV Series Overview:
MaximalDV Series Configuration Chart:
Total Output
Current
(16 outputs)
AL400XB2V ------
7A
5.4A
6.2A
AL600XB220 ------
11A
11.4A
11.2A
19
AL1024XB2V
19
AL1024XB2V
19.4
MaximalDV Series Features:
PTC Protected
Outputs
(auto-resettable)
2.5A 16 2.4A
2.5A 16
2.5A 16
2.5A 16
2.5A 16
Maximal11DV/Maximal33DV/Maximal55DV/Maximal77DV/Maximal75DV Access Power Controllers (PTC)
Power Supply Power Supply
Board Input Board Battery
Fuse Rating Fuse Rating
5A/250V 15A/32V
3A 5A/250V
3A 5A/250V 15A/32V
5A/250V
15A/32V
(AL1012XB220) (AL1012XB220)
5A
6.3A/250V
(AL1024XB2V)
(AL1024XB2V)
6A 5A/250V 15A/32V
------
and
