A-scan configuration
5.8 A-scan configuration
You can adjust the A-scan display on the screen to your
requirements.
N o t e
Some of these parameters are automatically
set by the instrument during calibration.
Setting the display range
You can set the display range for the echoes on the
screen on the basis of the measurement results to be
expected. This includes the setting of display range and
display delay.
Display range
You can use display range to set the display screen to
the thickness range you wish to use for your measure-
ments.
– In the function group MEASURE, select the function
DISPLAY RANGE.
– Select the required display range.
DMS Go+
Display delay
Make your choice of displaying the set display range
starting from the surface of the test object or in a section
starting earlier or later.
This allows you to shift the complete screen display and
consequently also the display zero.
If the display should start from the surface of the test ob-
ject, you have to set the display delay to 0.
– In the function group MEASURE, select the function
DISPLAY DELAY.
– Choose the required display delay.
Edition 4 (05/2014)
5 Operation
5-33
