When mounting the AP on the wall, keep the logo of Ruijie point upward.
The square feet should fit easily into the mounting slots. Do not forcibly push the AP into the slots.
After installation, verify that the AP is securely fastened.

(Optional) Securing the Access Point

1) Loosen the screw on the mounting bracket and enable the hidden lock.
Figure 3-1 Enabling the Hidden Lock
2) Align the square feet on the rear of the AP over the mounting holes on the bracket, slide the AP in the reverse
direction against the arrow on the mounting bracket until it clicks into place.
Figure 3-2 Mounting the AP on the Bracket
Installing the Access Point
·
