Configuration: Manual V.21 Answer Operation
Command: &F30
The &F30 configuration enables V.21 answer operation.
The modem configuration is as follows:
WorldBlazer - Active Configuration
BO El L2
Ml
P
Q1
VI Xl
YO
&C1 &D4 &GO &JO &LO &QO &R1 &S4 &T4 &XO
SOOO~O SOOl~O SOO2~43 SOO3~13 S004~10 S005~8 S006~2 SOO7~60
S008~2 SOO9~6 S010:0
SOll~70 S012~50 S0l8~O S025~5 S026~1
S038~0 S041~0
S045~0 S046~0 S047~4 S048~O
S050:1 S051:0
S056~17 S057~19
S058:0
S059~0 S060~O
S061:0
S062~15 S063~0
S064~0
S068:0
S069~O S090~O
S092~0
S09>8
S094:0 S100:1
Sl04~0 SlO5~1
Sl11:0
S1l2~1 S1l3~126 S1l4~0 S115~0 S151~4
S155~0 S180:0 S181:0
S183~25
S190:0 S191:6
S253~10 S254~255
S255~255
Configuration: Asynchronous/Synchronous &Q1
Command: &F32
The &F32 configuration enables asynchronous/
synchronous &Q1 operation. When the modem is not
online, the primary data and clock lines operate in
asynchronous mode. The modem switches to
synchronous mode when a connection to another modem
is established. The modem configuration is as follows:
WorldBlazer - Active Configuration
Bl El L2 Ml
p
Q2 Vl Xl YO
&C1 &D2 &GO &JO &LO &Q1 &R3 &S3 &T4 &XO
SOOO:l
SOOl~O S002~43 S003~13 S004~lO SOO5~8 S006~2 SOO7~60
SOO8~2 S009~6 SOlO~14 SOll~70 S012~50 S0l8~0 S025~5 S026~1
S038~O S041~O S045~O S046~0 S047~4 S048~0
S050:7
S051~252
S056~17
S057~19 S058~3 S059~O S060~0 S061~1 S062~15 S063~O
S064~0 S068~255 S069~O S090~0
S092~O
S093~8
S094~1 SlOO~O
SlO4~0 S105~1
S111~255 S112~1
S1l3~126 S114~O
S1l5~0 S151~4
S155~0
S180:0 S181:0
S183~25 S190~1 S191~7 S253~lO S254~255
S255~255
90257-01 Prestored Configurations A-13
