Configuration: Half-Duplex Transparent Synchronous
LPDA Dialing
Command: &F6
The &F6 configuration enables the modem to operate in
V.32his transparent, synchronous, half-duplex mode at
14,400 bps using LPDA dialing. The modem
configuration is as follows:
WorldBlazer - Active Configuration
Bl
El L2 Ml
P
QO Vl Xl YO
&C6 &D2 &GO &JO &LO &Q6 &R4 &S4 &T4 &XO
SOOO:l
SOOl~O SOO2~43 SOO3~13 SOO4~lO SOO5~8 SOO6~2 SOO7~60
SOO8~2 SOO9~6
SOlO~14 SOll~70 S012~50 S018~O
S025~5
S026:0
S038~O S041~O S045~O S046~O S047~4 S048~O
S050:7
S051~252
S056~17 S057~19 S058~3 S059~O S060~O
S061~1 S062~15 S063~O
S064~O S068~255 S069~O
S090~O S092~O S093~8 S094~1 SlOO~O
SlO4~O SlO5~1 S1l1~255 S1l2~1 S1l3~126
S1l4~O S1l5~O S151~4
S155~O
S180:0 S181:0
S183~25 S190~1 S191~7
S253:32
S254~255
S255~255
Configuration: IBM AS 400 V.2Sbis Bit-Synchronous
Operation
Command: &F7
The &F7 configuration enables the modem to operate in
V.32bis transparent, synchronous, half-duplex IBM
AS 400 mode with V.25bis synchronous dialing. The
modem configuration is as follows:
WorldBlazer - Active Configuration
Bl
El
L2 Ml
P
QO VO XO YO
&C6 &D2 &GO &JO &LO &Q6 &R4 &S4 &T4 &XO
SOOO:2
SOOl~O SOO2~43 SOO3~13
SOO4~lO SOO5~8 SOO6~2 SOO7~60
SOO8~2 SOO9~6 S010~14 SOll~70 S012~50 S018~O S025~5
S026:0
S038~O S041~O S045~O S046~O
S047~4
S048~O
S050:7
S051~252
S056~17 S057~19 S058~3 S059~O S060~O
S061:0
S062~15 S063~O
S064~O S068~255 S069~O S090~O S092~O S093~8 S094~1
SlOO~O
SlO4~O SlO5~1 S1l1~255 S1l2~1 S1l3~12
6
S1l4~O S1l5~O S151~4
S155~O
S180:0 S181:0
S183~25 S190~1 Sl91~7
S253:22
S254~255
S255~255
