Telebit WorldBlazer User Manual page 47

Configuration: Leased-Line Synchronous
Originate Mode
Command: &F12
The &F12 configuration is used in synchronous point-to-
point, 2-wire leased-line, V.32bis applications. The
modem connects automatically on a leased line to another
T3000 or WorldBlazer modem configured with the
AT&F13 command (or any properly configured V.32bis
modem) at 14,400 bps. The modem configuration is as
follows:
WorldBlazer - Active Configuration
B1 EO L2 M1
P
Q1
V1
Xl YO
&C1 &DO &GO &JO &L1 &Q6 &R3 &83 &T4 &XO
SOOO~O SOOl~O SOO2~43 S003~13 S004~10 S005~8 SOO6~2 S007:255
SOO8~2 SOO9~6 SOlO~14 SOll~70 S012~50 S018~0
S025~5
S026~1
S038~0 S041~O S045~O S046~0 S047~4 S048~O
8050:7
S051~252
S056~17 S057~19 S058~3 S059~O S060~O S061~1 S062~15 S063~0
S064:1
S068~255 S069~O S090~0 S092~O S093~8
8094:2
SlOO~O
S104~O S105~1 Slll~255
S1l2~1
S1l3~126
S1l4~0 S115~O S151~4
S155~0
S180:0 8181:0
S183~25 S190~1 S191~7
8253:0
S254~255
S255~255
Configuration: Leased-Line Synchronous
Answer Mode
Command: &F13
The &F13 configuration is used in synchronous point-to-
point, 2-wire leased-line, V.32bis applications. The
modem connects automatically on a leased line to another
T3000 or W orldBlazer modem configured with the
AT&F12 command (or any properly configured V.32bis
modem) at 14,400 bps. The modem configuration is as
follows:
WorldBlazer - Active Configuration
B1 EO
L2
M1
P
Q1 V1 Xl YO
&C1 &DO &GO &JO &L1 &Q6 &R3 &S3 &T4 &XO
8000:1
SOOl~O SOO2~43 SOO>13 S004~lO SOO5~8 S006~2
8007:255
S008~2 SOO9~6
S010~14 SOl1~70 S012~50 S018~O S025~5 S026~1
S038~O S041~O S045~O S046~O S047~4
S048~O
S050:7
S051~252
S056~17 S057~19 S058~3 S059~O S060~O S061~1 S062~15 S063~O
8064:1
S068~255 S069~O S090~O S092~O S093~8 S094:2 SlOO~O
SlO4~O SlO5~1 S111~255 S112~1 S113~126 S114~O S115~O S151~4
S155~O
8180:0
8181:0 S18>25
S190~1 S191~7
S253:0
S254~255
S255~255
