Functions
13.9

System Configuration

The MoRoS ADSL 2.1 PRO displays system data such as firmware version, serial
number, hardware revision or firmware checksum, together with short system
messages about events and errors in the menu "System" on the page "System
data". This information is helpful and should be known together with the config-
ured IP address if you contact the support. Furthermore, several links enable to
display system states and connection logs.
13.9.1

Displaying the System Log

The MoRoS ADSL 2.1 PRO allows to display the detailed system log in the menu
"System" on the page "System data". The number of displayed lines and the up-
date interval can be configured.
Configuration with the web interface
In order to view the detailed system messages via the web interface,
click on the link "Show the extensive system log".
In order to configure the display of the system log, enter on the page
"System log" into the field "Refresh after" the update interval of the log
in seconds as well as into the field "show last ... lines" the number of
lines to be displayed and select "OK".
13.9.2

Displaying the Last System Messages

The MoRoS ADSL 2.1 PRO displays short system messages about events and
errors in the menu "System" on the page "System data". For analysis purposes, you
can dispaly the last messages on the web interface.
Configuration via the web interface
In order to display the last system messages, click on the link "Show the
last system messages".
