  • Page 1 MoRoS LAN PRO 2.0 Dec-09...
  • Page 3 MNP is a registered trademark of Microcom Inc. IBM PC, AT, XT are registered trademarks of International Business Machine Corporation. INSYS ® is a registered trademark of INSYS MICROELECTRONICS GmbH. Windows™ is a registered trademark of Microsoft Corporation. Linux is a registered trademark of Linus Torvalds.

  • Page 4: Table Of Contents

    Contents Safety ........................6 Scope of Delivery ....................8 Usage According to the Regulations ..............9 Technical Data....................10 Physical Features ......................10 Technological Features .....................11 Display and Control Elements................12 Meaning of the Displays....................13 Function of the Control Elements ..................13 Connections.......................
  • Page 5 Contents 12.4 Inputs and Outputs......................56 12.4.1 Querying the State of the Inputs ................56 12.4.2 Configuring the Function of the Inputs ..............56 12.4.3 Configure SMS Dispatch....................57 12.4.4 Switch Outputs ........................ 58 12.5 Configurable Switch ......................59 12.5.1 Querying Configuration and Status of the Switch Ports ........59 12.5.2 Configuring Switch Ports ....................

  • Page 6: Safety

    Risk of death through shock hazard when touching it! The MoRoS LAN PRO 2.0 may not be used in wet or damp environments, or in or very close to water. Install the de- vice at a dry location, protected from water spray. Switch the power supply off before you do any work on a device which may have been in contact with moisture.
  • Page 7 MoRoS LAN PRO 2.0 Safety Note Damage due to chemicals! Ketones and chlorinated hydrocarbons dissolve the plas- tic housing and damage the surface of the device. Never let the device come into contact with ketones (e.g. acetone) or chlorinated hydrocarbons, such as dichloro-...

  • Page 8: Scope Of Delivery

    MoRoS LAN PRO 2.0 Scope of Delivery The scope of delivery for the MoRoS LAN PRO 2.0 includes all accessories listed below. Please check if all accessories are included in the box. If a part is missing or damaged, please contact your distributor.

  • Page 9: Usage According To The Regulations

    2006/42/EC.  Usage as data transmission device for a PLC. The MoRoS LAN PRO 2.0 must not be used for the following purposes and used or oper- ated under the following conditions:  Controlling or switching of machines and systems which do not comply with the directive 2006/42/EC.

  • Page 10: Technical Data

    Danger! Overvoltage. Fire hazard! The MoRoS LAN PRO 2.0 must be secured with a suitable fuse against overvoltage. All specified data was measured with nominal input voltage, at full load, and an ambient temperature of 25 . The limit value tolerances are subject to the usual variations.

  • Page 11: Technological Features

    MoRoS LAN PRO 2.0 Technical Data Technological Features Technological Feature Description 4-Port Ethernet Switch 10/100 Mbit/s full/half duplex auto sense; automatic detection of "crossover" or "patch" wiring. LAN ext interface 10/100 Mbit/s full/half duplex auto sense; automatic detection of "crossover"...

  • Page 12: Display And Control Elements

    Display and Control Elements MoRoS LAN PRO 2.0 Display and Control Elements Figure 1: LEDs on the front panel Position Description Status/VPN LED Data LED COM LED Power LED Status LED for Switch LAN 4 Status LED for Switch LAN 3...

  • Page 13: Meaning Of The Displays

    Press three times for a short Deletes all settings of the time within 2 seconds. MoRoS LAN PRO 2.0 and re- sets the device to the factory defaults. Table 5: Description of the functions and meaning of the control elements...

  • Page 14: Connections

    Connections MoRoS LAN PRO 2.0 Connections Front Panel Connections Figure 2: Connections on the front panel of the device Position Description Serial interface (RS232 socket V.24/V.28) Switch with 4 Ethernet ports (RJ45, 10/100 BT) Ethernet port (RJ45, 10/100 BT) Table 6: Description of the connections on the front panel of the device...

  • Page 15: Terminal Connections On The Top

    MoRoS LAN PRO 2.0 Connections Terminal Connections on the Top Figure 3: Connections on the top of the device Terminal Description Description OUT 1-NC Output1 normally closed OUT 1 Output 1 OUT 1-NO Output 1 normally open OUT 2-NC Output 2 normally closed...

  • Page 16: Terminal Connections On The Bottom

    Connections MoRoS LAN PRO 2.0 Terminal Connections on the Bottom Figure 4: Connections on the bottom of the device Terminal Description Description Ground Input 2 Input 2 Input 1 Input 1 Ground Reset Reset Input Ground 10 ... 60VDC Power supply 10 V - 60 V DC...

  • Page 17: Pin Assignment Of The Serial Interface

    MoRoS LAN PRO 2.0 Connections Pin Assignment of the Serial Interface Figure 5: 9-pin Sub-D socket at the device Signal Description Data Carrier Detect Receive Data Transmit Data Data Terminal Ready Ground Data Set Ready Request To Send Clear To Send...

  • Page 18: Function Overview

    The MoRoS LAN PRO 2.0 offers the following functions:  Configuration via the web interface All functions of the MoRoS LAN PRO 2.0 can be configured and set via a web interface. The access to the web interface is protected with a user name and passwort query.
  • Page 19 The MoRoS LAN PRO 2.0 has two potential-free switch outputs, which can be used for manual or time-controlled switching in an application. The MoRoS LAN PRO 2.0 also has digital inputs. One input can be used to estab- lish PPPoE connections.
  • Page 20  Port mirroring at the Ethernet switch for analysis purposes A port at the switch of the MoRoS LAN PRO 2.0 can reproduce a copy of the data at another network port of the switch. At this mirror port, the trans- mitted data can be read for analysis purposes (e.g.

  • Page 21: Meaning Of The Symbols And The Formatting In This Manual

    MoRoS LAN PRO 2.0 Meaning of the Symbols and the Formatting in this Meaning of the Symbols and the Formatting in this Manual This section describes the definition, formatting and symbols used in this manual. The various symbols are meant to help you read and find the information relevant to you.

  • Page 22: Installation

    Installation MoRoS LAN PRO 2.0 Installation This chapter describes how to mount the MoRoS LAN PRO 2.0 to a DIN rail, connect it to the power supply and uninstall it again. Danger! Exposed electrical components! Risk of death through electric shock hazard! Prior to the installation, switch the power of the cabinet off and secure it against being switched on again.
  • Page 23 Installation Mount the device to the DIN rail Instructions on how to mount the MoRoS LAN PRO 2.0 to a DIN rail: Position the device at the DIN rail as seen in the following diagram. There are two snap-in hooks at the outer edge of the DIN rail groove of the MoRoS LAN PRO 2.0.
  • Page 24 Installation MoRoS LAN PRO 2.0 Uninstall the device from the DIN rail Instructions on how to uninstall the MoRoS LAN PRO 2.0 from a DIN rail in a cabinet:  You will need a Philips screwdriver with a 4.5 mm blade.
  • Page 25 MoRoS LAN PRO 2.0 Installation Turn the Philips screwdriver into the direction of the MoRoS LAN PRO 2.0 as shown in the following figure.  The plastic spring of the snap-in hook is stretched. While you hold the plastic spring of the snap-in hook stretched, pull the Mo- RoS LAN PRO 2.0 away from the DIN rail.

  • Page 26: Initial Operation

    This chapter describes how to activate the MoRoS LAN PRO 2.0, i.e. how to connect the MoRoS LAN PRO 2.0 to a PC, and how to prepare it for the configuration. Connect the MoRoS LAN PRO 2.0 to an LAN and a PC How to connect the MoRoS LAN PRO 2.0 via a PC for configuration and to...
  • Page 27 PRO 2.0 receives power. If yes, most probably the wrong IP address is set in the MoRoS LAN PRO 2.0. In this case, reset your device to the factory defaults by pressing the reset key three times for a short time and repeat step 2.

  • Page 28: Operating Principle

    11.1 Operating the Web Interface The web interface allows easy configuration of the MoRoS LAN PRO 2.0 using a web browser. All functions of the MoRoS LAN PRO 2.0 can be configured via the inter- face. The operation is mostly self-explanatory. The interface also provides an online help feature, which describes the meaning of possible settings of the MoRoS LAN PRO 2.0.
  • Page 29 MoRoS LAN PRO 2.0 Operating Principle  The start page of the web interface is displayed. Use the menu on the left side to select the menu item, in which you want to change settings. Enter the required settings. Click on the button OK on the according configuration page to save the set- tings.

  • Page 30: Access Via The Https Protocol

    MoRoS LAN PRO 2.0) as well as encrypting the data transmission. If the MoRoS LAN PRO 2.0 is accessed via the HTTP S protocol fort he first time, the browser indicates that the MoRoS LAN PRO 2.0 uses an invalid security certificate.

  • Page 31: Functions

    12.1.1 Web Interface (User Name, Password, Remote Configuration) The web interface is used to configure the MoRoS LAN PRO 2.0. It is protected against unauthorized access by a user name and password query. The web interface can be con- figured for a configuration from a computer in the internal network or for remote con- figuration.

  • Page 32: Configure Ip Addresses Or Retrieve Via Dhcp

    12.1.2 Configure IP Addresses or Retrieve via DHCP It must be possible to access the MoRoS LAN PRO 2.0 in the LAN under a certain IP ad- dress. You must assign a static IP address for this. Configuration with the web interface In order to configure a static IP address, change in the menu "Basic Settings"...

  • Page 33: Lan (Ext)

    LAN, which can be accessed via an Ethernet cable. Then, you ha- ve to configure an IP address for the LAN ext interface of the MoRoS LAN PRO 2.0. This IP address must be in the address range of the external LAN, into which the MoRoS LAN PRO 2.0 shall route.

  • Page 34: Configuring Dsl

    The MoRoS LAN PRO 2.0 can connect to a WAN using a DSL modem. Connect the DSL modem to the LAN ext interface of the MoRoS LAN PRO 2.0. The MoRoS LAN PRO 2.0 can communicate with the DSL modem via a PPPoE connection. You must configure the LAN ext interface for PPPoE operation for this.

  • Page 35: Configuring Leased Line Operation

    12.2.4 Configuring Leased Line Operation You can configure the MoRoS LAN PRO 2.0 to permanently maintain a DSL connection. In this operating mode, the MoRoS LAN PRO 2.0 will immediately establish the connection after system start. The MoRoS LAN PRO 2.0 checks the connection for its function peri- odically.

  • Page 36: Configuring Routing

    MoRoS LAN PRO 2.0 12.2.5 Configuring Routing Routing is the core function of the MoRoS LAN PRO 2.0. Routing means that the MoRoS LAN PRO 2.0 routes incoming data packets according to certain rules defined by you to certain network devices.

  • Page 37: Setting Up A Dialling Filter

    MoRoS LAN PRO 2.0 Functions 12.2.6 Setting up a Dialling Filter The dialling filter can restrict the network traffic which could trigger a dial-out connec- tion establishment. All packets with external destination initiate a connection estab- lishment without dialling filter. If the dialling filter is enabled, only the packets, which are permitted by the rules, can initiate a connection establishment.

  • Page 38: Creating Or Deleting A Firewall Rule

    NAT and port forwarding are used. Only the public IP address of the MoRoS LAN PRO 2.0 can be reached in the Internet. This IP address can still be used to access the local end terminals in the network of the MoRoS LAN PRO 2.0 from the Internet, if NAT and port forwarding are used.

  • Page 39: Defining The Exposed Host

    The exposed host contains all packets which have not been requested by the local net- work of the MoRoS LAN PRO 2.0 or which have not been forwarded to a participant in the local network by a port forwarding rule. If no exposed host is configured, these incoming packets are discarded.

  • Page 40: Vpn

    The data is transmitted tamper-proof to a destination and can not be read by third parties. You can use the MoRoS LAN PRO 2.0 as an OpenVPN server or an OpenVPN client. Figure 6 shows a sample VPN configuration. One MoRoS LAN PRO 2.0 is configured as OpenVPN server and a second MoRoS LAN PRO 2.0 as OpenVPN client here.

  • Page 41: Openvpn Server Basic Settings

    The VPN basic settings are used to de- fine which port of the MoRoS LAN PRO 2.0 is used to create the VPN tunnel and if the VPN transmission is performed with the UDP or the TCP protocol. You can also define if...
  • Page 42 Functions MoRoS LAN PRO 2.0 The VPN transmission protocol is selected with the radio buttons "UDP" or "TCP". We recommend using UPD to minimise latency. In order to enable remote VPN terminals to change its IP during a connection ("Floating"), check the checkbox "Remote terminal is allowed to change its IP address (float)".

  • Page 43: Configuring Openvpn Server

    In the following, you will find a description of how to configure the MoRoS LAN PRO 2.0 as VPN server. How to configure the VPN server of the MoRoS LAN PRO 2.0 without authentication or with one of the two supported authentication methods...
  • Page 44 Functions MoRoS LAN PRO 2.0 Open the MS-DOS prompt Switch into the directory "easy-rsa" of the OpenVPN installation. (e.g. with the following command: cd C:\Program fi- les\OpenVPN\easy-rsa\  The file vars.bat can be edited to adjust it for your purposes (e.g. by adjust- ing the default values).
  • Page 45 You will find a file with the name "dh1024.pem" in the sub-directory "keys". Creating a private key and certificates for the server and clients How to create the private keys and certificates for the MoRoS LAN PRO 2.0 VPN Server and the VPN Clients.
  • Page 46 You have already created a CA certificate, Diffie-Hellman parameters and private keys and certificates for the server and the clients. Navigate in the web interface of the MoRoS LAN PRO 2.0 to the menu "LAN (ext)" to the page "OpenVPN server".
  • Page 47  The MoRoS LAN PRO 2.0 OpenVPN server is now completely configured for the certificate-based authentication.  To be able to establish an OpenVPN connection via the MoRoS LAN PRO 2.0, you must activate the OpenVPN Server.
  • Page 48  In order to configure the VPN remote terminal, use the function "Create sample configuration file for remote terminal".  To be able to establish an OpenVPN connection via the MoRoS LAN PRO 2.0, you must activate the OpenVPN Server.
  • Page 49 As an alternative, you may also upload an already existing key. For this, click in the section "Upload key or certificates" on "Browse...", select a key file and then click on "OK" to upload the file to the MoRoS LAN PRO 2.0. ...

  • Page 50: Openvpn Client Basic Settings

    12.3.4 OpenVPN Client Basic Settings You can use the MoRoS LAN PRO 2.0 as VPN client, if you want to connect to a VPN server via an unsecured network. This section describes the basic settings for the VPN client. The basic settings of the MoRoS LAN PRO 2.0 are reasonable factory defaults, which you need to adjust to the VPN which will be connected to the MoRoS LAN PRO 2.0.
  • Page 51 MoRoS LAN PRO 2.0 Functions check the checkbox "Remote terminal is allowed to change its IP address (flo- at)". This setting is activated by default. In order to enable or disable LZO compression, check or uncheck the checkbox "Activate LZO compression". If already strongly compressed data (e.g. jpg) is transmitted, the compression will have hardly any effect;...

  • Page 52: Configure Openvpn Client

    Configuring the OpenVPN Client with or without authentication In the following, you will find a description of how to set up the MoRoS LAN PRO 2.0 as OpenVPN client. How to configure the OpenVPN client of the MoRoS LAN PRO 2.0...
  • Page 53 You have received a CA certificate suitable for your VPN, as well as a private key and a certificate from the VPN administration or created them yourself. Navigate in the web interface of the MoRoS LAN PRO 2.0 to the menu "LAN (ext)" to the page "OpenVPN client".
  • Page 54 Functions MoRoS LAN PRO 2.0  To be able to establish an OpenVPN connection via the MoRoS LAN PRO 2.0, you must activate the OpenVPN Client. Configuring an OpenVPN client without authentication How to configure the MoRoS LAN PRO 2.0 OpenVPN client without using an authentication method.
  • Page 55 Click on OK to save your settings.  The OpenVPN client is now configured for a VPN connection with authenti- cation via static keys.  To be able to establish an OpenVPN connection via the MoRoS LAN PRO 2.0, you must activate the OpenVPN Client.

  • Page 56: Inputs And Outputs

    Configuring the Function of the Inputs The MoRoS LAN PRO 2.0 can send an SMS to a phone number if input 1 is closed and es- tablish a pre-configured dial-out connection, as soon as input 2 is closed for 4 seconds, i.e.

  • Page 57: Configure Sms Dispatch

    12.4.3 Configure SMS Dispatch The MoRoS LAN PRO 2.0 can send an SMS to a phone number when closing input 1. The pulse is distinguished between a long pulse with a duration of a minimum of 4 seconds, and individual pulses, which are shorter than 1 second.

  • Page 58: Switch Outputs

    MoRoS LAN PRO 2.0 12.4.4 Switch Outputs The MoRoS LAN PRO 2.0 has digital outputs, whose status can be queried and changed via the web interface. The outputs can also be operated daily at a certain time. Moreover, it is possible to oper- ate the outputs by establishing a PPP connection or an OpenVPN tunnel.

  • Page 59: Configurable Switch

    Querying Configuration and Status of the Switch Ports The switch of the MoRoS LAN PRO 2.0 is configurable. This means that you can determine for each switch port individually which transmission rate should be used or if it is sup- posed to be operated in half-duplex or full-duplex mode.

  • Page 60: Configuring The Led Display Of The Switch Ports

    Functions MoRoS LAN PRO 2.0 12.5.3 Configuring the LED Display of the Switch Ports You can determine how the events at the network and the states of the switch ports are displayed at the switch port status LEDs. We recommend not to change the basic settings and to change the displays only temporarily for diagnosis purposes.

  • Page 61: Server Services

    12.6.1 Setting up DNS Forwarding You may use the MoRoS LAN PRO 2.0 as DNS relay server. When the MoRoS LAN PRO 2.0 is configured as DNS server at the locally connected network devices, the MoRoS LAN PRO 2.0 will either forward the DNS queries to the previously configured DNS servers in the Internet, or will use the IP addresses sent during the PPP connection setup as DNS server.

  • Page 62: Setting Up The Dhcp Server

    The validity of the IP addresses allocated by the DHCP server are controlled via the "Lease time". If there is already a DHCP server in the net- work, in which the MoRoS LAN PRO 2.0 is used, this function must absolutely be disabled in the MoRoS LAN PRO 2.0.

  • Page 63: Setting Up The Serial Ethernet Gateway

    12.6.5 Configuring the Proxy Server The MoRoS LAN PRO 2.0 provides a proxy server. This does not serve as a cache for fre- quently accessed websites. It is used to delay the connection timeouts for dial-up con- nections that load slowly (e.g. via modem) and to filter undesired URLs. (e.g.

  • Page 64: Configuring An Url Filter

    12.6.6 Configuring an URL Filter With the help of the URL filter, the proxy of the MoRoS LAN PRO 2.0 can restrict possible URLs, which can be accessed by computers from the internal network of the MoRoS LAN PRO 2.0. This will allow only access to URLs which are entered in the filter list. All other URLs are blocked.

  • Page 65: System Configuration

    "System" on the page "System data". For analysis pur- poses, you can see the detailed messages of the MoRoS LAN PRO 2.0 on the web inter- face.

  • Page 66: Configuring Time And Time Zone

    12.7.4 Resetting the Device You can reset the MoRoS LAN PRO 2.0 via the web interface or by pressing the reset key on the front of the device. You can simply restart your device or reset all settings to the factory defaults.

  • Page 67: Updating The Firmware

    12.7.5 Updating the Firmware You can update the firmware of the MoRoS LAN PRO 2.0. The firmware is a combination of operating system and programs, in which the functions of the MoRoS LAN PRO 2.0 are implemented. o update the firmware, you will need a file with a new firmware, which you can obtain from your sales partner or from INSYS MICROELECTRONICS.
  • Page 68 If they match, the file has been uploaded correctly and you can proceed with the update. The time until the file is completely transmit- ted to the MoRoS LAN PRO 2.0 varies, depending on the firmware size. Confirm the query with Yes.

  • Page 69: Downloading The Configuration File

    You may upload a previously downloaded configuration file to the MoRoS LAN PRO 2.0, to replace the current configuration of the MoRoS LAN PRO 2.0 by the settings in the file. Uploading the Configuration File of the MoRoS LAN PRO 2.0 ...

  • Page 70: Sending Single "Ping" Packets

    MoRoS LAN PRO 2.0 12.7.8 Sending Single "Ping" Packets The MoRoS LAN PRO 2.0 can send single "Ping" packets. This enables to test, whether a specific machine is available in the network, easily. Optionally, the single "Ping" can be repeated regularly.

  • Page 71: Waste Disposal

    MoRoS LAN PRO 2.0 Waste Disposal Waste Disposal 13.1 Repurchasing of Legacy Systems According to the new WEEE guidelines, the repurchasing and recycling of legacy systems for our clients is regulated as follows: Please send those legacy systems to the following address, carriage prepaid:...

  • Page 72: Licenses

    MoRoS LAN PRO 2.0 Licenses The software technologies and programs of the firmware used in the MoRoS LAN PRO 2.0 are partly bound to the following licenses. The source code of the firmware components of the MoRoS LAN PRO 2.0 which are bound to these licenses may be obtained from INSYS MICROELECTRONICS on request.
  • Page 73 MoRoS LAN PRO 2.0 Licenses included without limitation in the term "modification".) Each licensee is addressed as "you". Activities other than copying, distribution and modification are not covered by this License; they are out- side its scope. The act of running the Program is not restricted, and the output from the Program is cov- ered only if its contents constitute a work based on the Program (independent of having been made by running the Program).
  • Page 74 Licenses MoRoS LAN PRO 2.0 so on) of the operating system on which the executable runs, unless that component itself accompanies the executable. If distribution of executable or object code is made by offering access to copy from a designated place, then offering equivalent access to copy the source code from the same place counts as distribution of the source code, even though third parties are not compelled to copy the source along with the object code.

  • Page 75: Gnu Library General Public License

    MoRoS LAN PRO 2.0 Licenses THE PROGRAM, TO THE EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT WHEN OTHER- WISE STATED IN WRITING THE COPYRIGHT HOLDERS AND/OR OTHER PARTIES PROVIDE THE PROGRAM "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED, IN- CLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FIT- NESS FOR A PARTICULAR PURPOSE.
  • Page 76 Licenses MoRoS LAN PRO 2.0 the program into proprietary software. To prevent this, we have made it clear that any patent must be licensed for everyone's free use or not licensed at all. Most GNU software, including some libraries, is covered by the ordinary GNU General Public License, which was designed for utility programs.
  • Page 77 MoRoS LAN PRO 2.0 Licenses  a) The modified work must itself be a software library.  b) You must cause the files modified to carry prominent notices stating that you changed the files and the date of any change.
  • Page 78 Licenses MoRoS LAN PRO 2.0 stricted, regardless of whether it is legally a derivative work. (Executables containing this object code plus portions of the Library will still fall under Section 6.) Otherwise, if the work is a derivative of the Library, you may distribute the object code for the work under the terms of Section 6.
  • Page 79 MoRoS LAN PRO 2.0 Licenses work based on the Library), you indicate your acceptance of this License to do so, and all its terms and conditions for copying, distributing or modifying the Library or works based on it. 10. Each time you redistribute the Library (or any work based on the Library), the recipient automatically receives a license from the original licensor to copy, distribute, link with or modify the Library subject to these terms and conditions.

  • Page 80: Other Licenses

    Licenses MoRoS LAN PRO 2.0 FAILURE OF THE LIBRARY TO OPERATE WITH ANY OTHER SOFTWARE), EVEN IF SUCH HOLDER OR OTHER PARTY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES 14.3 Other Licenses OpenVPN license: ------------------------ Copyright (C) 2002-2005 OpenVPN Solutions LLC <info@openvpn.net>...
  • Page 81 MoRoS LAN PRO 2.0 Licenses THIS SOFTWARE IS PROVIDED BY THE OpenSSL PROJECT ``AS IS'' AND ANY EXPRESSED OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO...

  • Page 82: Glossary

    Domain Name System. Service which is used to transform domain names into IP addresses. Domain name: The domain is the name of an Internet site (e.g. insys-tec). It consists of a name and an extension (top level domain, e.g. .de), (e.g. insys-tec.de).
  • Page 83 MoRoS LAN PRO 2.0 Glossary Port: (1) Jack at the switch where Ethernet devices are connected (2) Part of a socket for data connections Port forwarding: Network rules, which route data packets from certain senders to special recipients in a network.

  • Page 84: Tables And Diagrams

    Tables and Diagrams MoRoS LAN PRO 2.0 Tables and Diagrams 16.1 List of Tables Table 1: Physical Features ........................10 Table 2: Technological Features ......................11 Table 3: Description of the LEDs on the front panel..............12 Table 4: Meaning of the LED displays ....................13 Table 5: Description of the functions and meaning of the control elements......13...

  • Page 85: Index

    MoRoS LAN PRO 2.0 Index Index Access data ...........34 Data LED ..........12, 13 Accessories ............. 8 Date..............65 Additional information ......21 DCD ..............63 Alternative results ........21 Default route.........34, 36 Ambient temperature .......10 Default settings...........66 Analysis purposes ....19, 60, 64, 65 Destination IP address.......38...
  • Page 86 Index MoRoS LAN PRO 2.0 Filter list............64 Max. current load........10 Firewall ........19, 38, 64, 82 Max. switch voltage ........10 Firewall rule..........38 Maximum connect time ......34 Firmware ..........20, 67 Menu ..............29 Firmware checksum........64 Message dispatch ........56 Firmware update ........20 Moisture ............
  • Page 87 MoRoS LAN PRO 2.0 Index Power supply......22, 23, 24, 26 Status/VPN LED ........12, 13 PPP connection ..........56 Switch......... 11, 14, 19, 58, 83 PPPoE............34, 83 Switch LED.............13 PPP-over-Ethernet ........18 Switch Outputs..........19 Prerequisites ..........21 Switch port ..........58, 59 Private key ............46 Switch port status LED ......59...
