Configuring VLAN

The switch of the MoRoS ADSL 2.1 PRO can be divided in up to four VLANs. The
VLANs are described as VLAN A, VLAN B, VLAN C, and VLAN D. The ports 1 to 4
are the switch ports accessible from outside. The device itself is connected to the
4-port switch via an internal port. The belonging of a port to a VLAN can be
defined. The device can also belong to a VLAN. Each Ethernet packet that belongs
to a VLAN will be marked by an identifier (tag). The VLAN tag contains the VLAN ID
amongst others. Each port that belongs to a VLAN, will insert the VLAN tag
automatically for the received packets, if it not already contained in the packet.
Configuration via the web interface
In order to enable the VLAN configuration, check in the "Switch" menu
on the "VLAN configuration" page the checkbox "Activate VLAN
configuration".
In order to assign a port or the router to a VLAN, check the respective
checkbox in the configuration matrix.
In order to specify a VLAN ID for a >VLAN, enter it into the field "VLAN
ID".
In order to specify for a port that belongs to a VLAN, whether it shall
insert a VLAN tag into every received packet, or remove a possibly
already existing one, use the radio buttons "Insert VLAN tag" or "Remove
VLAN tag" for the respective port. If a port shall belong to several
VLANs, the VLAN tag must not be removed. The device connected to
this port must be able to interpret these VLAN tags. The VLAN tags will
always be removed for packets to the router.
Save your settings by clicking "OK".
78
Note
Loss of availability!
The configuration will immediately be transferred to the
switch after clicking on "OK". This may result that the
device cannot be accessed any more.
Therefore, configure the set VLAN on your locally
connected device accordingly.
