MoRoS ADSL 2.1 PRO
13.9.5

Update

You can update the MoRoS ADSL 2.1 PRO with a new firmware or provide a new
configuration using the web interface. A detailed description about these processes
can be found in the following sections "Updating the Firmware" and "Uploading
the Configuration File" of this manual.
Moreover, a daily automatic update of firmware files, configuration files (binary and
ASCII) or sandbox image files is possible. These must be provided on a server
accordingly for this.
Configuration via the web interface
In order to enable the automatic update, check in the "System" menu on
the "Update" page the checkbox "Activate automatic daily update".
In order to select the file transmission protocol, select the radio button
"HTTP" or "FTP".
In order to specify the storage location of the update files, enter the IP
address or the domain name of the server into the "Server" field and the
respective port into the "Port" field. It is also possible to specify sub-
directories of the server that are to be searched for the files.
In order to define a fix, MAC-depending time for the daily update, select
under "Update time" the radio button "depending on MAC".
In order to define a user-defined time for the daily update, select under
"Update time" the radio button "fix" and enter the time for the update.
In order to perform the daily update directly upon WAN connection
establishment, select under "Update time" the radio button "every time
after connecting to WAN".
If the file access is to be protected by an authentication, enter the
respective access data into the fields "User name" and "Password".
In order to initiate the automatic update immediately, check the
checkbox "Search for updates now".
Save your settings by clicking "OK".
In order to upload a firmware or configuration file (binary or ASCII), click in
the section "Manual update" on the "Browse..." button. Then, select in the
"Upload file" window the desired image file on the respective data carrier
and click on the "Open" button. Click on "OK" then to upload the file.
Note
Loss of availability!
Upon changing the configuration,it may happen that your
MoRoS ADSL 2.1 PRO cannot be accessed for a further
configuration (e.g. by changing the IP address).
Check critical settings, like IP address or access data (user
name, passwords) very carefully.
