Functions
13.5

Configurable Switch

13.5.1

Querying Configuration and Status of the Switch Ports

The switch of the MoRoS ADSL 2.1 PRO is configurable. This means that you can
determine for each switch port individually which transmission rate should be used
or if it is supposed to be operated in half-duplex or full-duplex mode. You may also
control via the web interface, to which switch port a cable is connected and if a
physical connection exists.
Configuration via the web interface
You can see the current configuration of the individual switch ports in
the menu "Switch" on the page "Port configuration" next to the port list.
The coloured fields indicate whether a cable is connected to the switch.
These fields indicate the four switch ports. The boxes are green if there is
a network cable connected, and red if there is no cable connected or if
no physical connection exists to the network.
