MoRoS ADSL 2.1 PRO Functions
Configuration via the web interface
In order to enable the modem emulator, check in the menu "Serial
Ethernet" on the page "Modem emulator" the checkbox "Activate
modem emulator".
In order to enable the echo function using the ATE command in the
modem emulator, check the checkbox "Enable echo (ATE)".
In order to disable the answers using the ATQ command in the modem
emulator, check the checkbox "Disable answers (ATQ)".
In order to enable the verbose answers using the ATV command in the
modem emulator, check the checkbox "Enable verbose answers (ATV)".
In order to configure the number of ring tones until call acceptance,
enter the number of ring tones into the field "Number of rings until
connection is answered (ATS0)".
In order to configure the default answer for unknown commands, enter
this into the field "Default answer for unknown commands". If nothing is
entered here, the message "ERROR" is returned in case of an unknown
or invalid AT command.
In order to download the current AT answer file, click on the link
"Download current AT answer file".
In order to upload an AT answer file, click on the "Browse..." button and
locate the respective file. The file will be uploaded after clicking on "OK".
This file must be a text file, which defines an associated answer for each
desired AT command. Each line in this text file defines an "command-
answer-pair" in the form <i="Serial Ethernet Gateway Version 1.0">. The
part preceding the "=" indicates the command (here "i" for ati; the "at"
must be removed) and the part following in quotation marks indicates
the associated answer (here "Serial Ethernet Gateway Version 1.0"). In
this case, the message "Serial Ethernet Gateway Version 1.0" would be
replied on the ati command. A multi-line answer within the quotation
marks is possible. Capitalization is ignored. Moreover, the order of the
entries must be observed. If an answer for the atxy command and the atx
command is defined for example, the entry for the atxy command must
be entered before the entry for the atx command, because otherwise the
entry for the atx command would be found first and processed after
entering the atxy command, before looking for a aty command, which
does not exist.
Save your settings by clicking "OK".
