Connections
8.6
ADSL line connection RJ45
Figure 6: RJ45 connector
Pin
Signal
1
n/c
2
n/c
3
n/c
4
a
5
b
6
n/c
7
n/c
8
n/c
Table 12: Description of the pin allocation of the RJ45 connector
28
Description
Not connected
Not connected
Not connected
ADSL line connection wire a
ADSL line connection wire b
Not connected
Not connected
Not connected
MoRoS ADSL 2.1 PRO
