Functions
13.6

Serial Ethernet gateway

13.6.1

Setting up the Serial Ethernet Gateway

The serial Ethernet gateway enables the addressing of serial end devices from the
local network of the MoRoS ADSL 2.1 PRO or via the WAN interface, which are
connected to the serial interface. The data which is sent to a configurable network
port of the MoRoS ADSL 2.1 PRO is output at the serial interface. The connection
to the serial Ethernet gateway can either be maintained permanently (leased line
mode) or set-up if required (connection on request).
If the serial Ethernet gateway is enabled, a redundant communication device
cannot be used at the serial interface. If the sandbox is enabled and the serial
interface is reserved for the sandbox in addition, the sandbox has priority, i.e.
redundant communication device and serial Ethernet gateway are disabled. The
serial Ethernet gateway can be made dependent of the status of input 2 in the
menu "In- / Outputs" on the page "Inputs".
Configuration via the web interface
In order to enable the serial Ethernet gateway, check in the menu "Serial
Ethernet" on the page "Serial Ethernet" the checkbox "Activate serial
Ethernet gateway".
In order to display the current state of the serial Ethernet gateway, click
on the link "Serial Ethernet gateway current state".
In order to display the log of the serial Ethernet gateway, click on the link
"Serial Ethernet gateway log".
In order to configure the display of the serial Ethernet gateway log, enter
on the page "Serial Ethernet gateway log" into the field "Refresh after"
the update interval of the log in seconds as well as into the field "show
last ... lines" the number of lines to be displayed and select "OK".
In order to configure the operation mode of the serial Ethernet gateway ,
select either the radio button "Leased line mode" or "Connection on
request".
In order to use an IPT connection, check the checkbox "Use IPT". In this
case, the IPT slave must also be configured and enabled in the menu
"Server services" on the page "IPT".
In order to increase the time between connection attempts in leased line
mode, check the checkbox "increase reconnection interval". In this case,
the interval between the connection attempts will increase (1, 5, 15, 30,
60 minutes). Otherwise, the MoRoS ADSL 2.1 PRO will try to establish a
connection every minute, if this is interrupted.
