MoRoS ADSL 2.1 PRO
6

Technical Data

6.1 Physical Features
All specified data was measured with nominal input voltage, at full load, and an
ambient temperature of 25 . The limit value tolerances are subject to the usual
variations.
Physical Feature
Operating voltage
Power consumption
Level inputs
Current consumption of an active input
against GND (internal +5V)
Switch output, maximum switch
voltage
Switch output, maximum current load
Weight
Dimensions (Width x Depth x Height)
Temperature range
Maximum permissible humidity
IP rating
Table 1: Physical Features
Value
minimum 10 V DC
maximum 60 V DC
6 W
HIGH level = 3-12 V (contact open or
voltage strength for external supply)
LOW level = 0-1 V
Typically 0.35 mA (when enabling the
input by connecting to GND)
30 V (DC) / 42 V (AC)
1 A (DC) / 0.5 A (AC)
370 g
100 mm x 110 mm 75 mm
-20 °C ... 55 °C
95% non-condensing
Housing IP40, Terminals IP20
