13.4

Inputs and Outputs

13.4.1

Querying the State of the Inputs

The MoRoS ADSL 2.1 PRO has digital inputs, which may trigger a PPP connection
set-up, a message dispatch via e-mail, an OpenVPN tunnel set-up, a PPTP tunnel
set-up, an IPsec tunnel set-up, or the set-up of a serial Ethernet connection. The
inputs are closed when connected to GND. They are opened when there is no
connection to GND. The states of the two inputs can be queried via the web
interface.
Configuration via the web interface
In order to query the status of the inputs, click in the menu "In-
/ Outputs" on the page "Inputs" on the "Refresh" button. After the page
has been reloaded, the states of the inputs are displayed next to "Input
1:" and "Input 2:".
