Step Action
In the table, where both
the Label Value and TOF
Value are at least 20,
subtract the amounts and
record the result as a
Difference Value (see
K
below).
Identify the largest
Difference Value and then
the corresponding Gain
Number.
Gain Number
00
01
02
...
15
16
17
18
19
...
31
Step Action
Scroll to the Gain Number
determined in the
L
previous step and then
press the ENTER Key.
(continued)
80
Displayed Message
GAIN TRAN
*31
<yyy>
- Or, for reflective media:
GAIN REFL
*31
<yyy>
Sample Calibration Table
Label Value TOF Value
252
250
248
...
188
184
179
174
170
...
132
Displayed Message
GAIN TRAN
*18
<yyy>
- Or, for reflective media:
GAIN REFL
*18
<yyy>
Comment
In this example, Gain
•
Number 18 is chosen
because, where both
(0 - 31)
values are at least
twenty, it has the
highest Difference
Value.
(0 – 31)
This Gain Number will
•
be used to resample
the media.
Difference Value
248 4
245 5
234 14
... ...
63 125
51 133
38 141
25 149
19 N/A
... ...
14 N/A
Comment
(0 - 31)
After ENTER is pressed,
an asterisk (*) appears
to denote selection.
(0 – 31)
