Step Action
Press the MENU Key.
Then, with MEDIA
B
SETTINGS highlighted,
press the ENTER Key.
Using the DOWN ARROW
Key, scroll to SENSOR
CALIBRATION then press
C
the ENTER Key. Scroll to
ADVANCED ENTRY and
press the ENTER Key.
Scroll to SENSOR GAIN
D
then press the ENTER Key.
Place the label under the
Sensor Eye Mark and latch
the Head Lift Lever. Using
E
the DOWN ARROW Key,
scroll to GAIN TRAN 00
and press the ENTER Key.
Record the sensor reading
('yyy') as a Label Value in
a table similar to the one
F
shown below, with 32
rows, four columns, and
similar headings.)
Gain Number
00
01
02
...
31
(continued)
A-Class
Displayed Message
MEDIA SETTINGS
ADVANCED ENTRY
SENSOR GAIN
GAIN TRAN
*00 (0 – 31)
<yyy>
- Or, for reflective media:
GAIN REFL
*00 (0 – 31)
<yyy>
GAIN TRAN
*00 (0 – 31)
<yyy>
- Or, for reflective media:
GAIN REFL
*00 (0 – 31)
<yyy>
Sample Calibration Table
Label Value TOF Value
252
Comment
Press the ESC Key to
abort this procedure.
Press the ESC Key to
abort this procedure.
Press the ESC Key to
abort this procedure.
If using preprinted
•
labels, ensure that
the sampling area is
free of text, graphics,
and perforations.
After ENTER is
•
pressed, an asterisk
(*) appears to denote
selection.
The sensor reading,
where 'yyy' represents
the numeric sample, is
useful in locating the
best sensor position over
the media.
Difference Value
77
